Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V

Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V
Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V

Large Image :  Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V

Product Details:
Place of Origin: Guangdong,China
Brand Name: GSKA
Certification: CE ISO
Model Number: Climatic Test Chamber
Payment & Shipping Terms:
Minimum Order Quantity: negotiate
Price: negotiate
Packaging Details: The outer packing is first packed with foam plastic, and then reinforced with strong wooden cases.
Delivery Time: 15-20working days after received deposit
Payment Terms: L/C, T/T,
Supply Ability: 150 Set / Sets per Month

Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V

Description
Low Temperature: 20 Dgree To -70 Dgree High Temperature: 150 Degree(200dgree)
Power: 220V , 50Hz Controller Resolution: ±0.3℃;±2.5%RH
Body Materials: SUS#304 Stainless Steel Plate QTemperature Uniformity: ±2.0℃
Condenser: Water-cooled Condensing Agent Customized Support: OEM
High Light:

Lab Testing Equipment

Exported temperature and humidity climate chamber Application:


Exported temperature and humidity climate chamber is also called environment testing machine, used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.



Working Principle:

This is so called Fast Shipping Thermal Shock Test Chamber, Thermal Chamber, Thermal Shock Chamber.


Sample is placed in the test chamber, more extreme temperature than test temperature can be set in high-temperature chamber and low-temperature chamber. When it comes to low temperature test, cold chamber door open, and low-temperature chamber working together with test chamber.


When converted into high-temperature test, cold chamber door closed, hot chamber door are opened, and test chamber working together with high-temperature chamber.


Conversion of mechanical action (transferring from high temperature to low temperature or low temperature to high temperature) can be completed in less than 1second, and the temperature can be quickly stabilized. During the whole test, test sample is no need to be moved, and without any human intervention.


Specification:



Model GSKA80 GSKA150 GSKA220 GSKA800 GSKA1000
Internal Dimension
WxHxD (mm)
400x500x400 500x600x500 600x750x500 1000x1000x800 1000x1000x1000
Internal Dimension WxHxD (mm) 950x1650x950 1050x1750x1050 1200x1900x1150 1600x2000x1450 1600x2100x1450
Temperature Range Low Temperature(A:25ºC B:0ºC C:-20ºC D:-40ºC E:-60ºC F:-70ºC)
High Temperature 150ºC
Humidity Range 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optiona , need Dehumidifier)
Indication relolution/Distribution
uniformity of temperature and humidity
0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H.
Control Accuracy of Temperature
and Humidity
±0.5ºC; ±2.5% R.H.
Temperature Rising/
Falling Velocity
Temperature rising approx. 0.1~3.0ºC/min ; temperature falling approx. 0.1~1.5ºC/min;
( Falling Min.1.5ºC/min is optional)
Inner and Outer Material Interior material is SUS 304# stainless steel, exterior is stainless steel or SEE cold-rolled steel with paint coated.
Insulation Material Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials
Cooling System Wind cooling or water cooling, (single segment compressor-40ºC, double segment compressor -70ºC)
Protection Devices Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection
Optional Accessories Inner door with operation hole , Recorder, Water Purifier, Dehumidifier
Compressor French Tecumseh Brand, Germany Bizer Brand
Power AC220V 1∮ 3 lines, 50/60HZ , AC380V 3∮ 5 lines , 50/60HZ
Approx. Weight (Kg) 150 180 250 400 450





Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V 0Chemical Environment Temperature And Humidity Climatic Test Chamber AC220V 1


We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency



- Climatic and refrigerating chambers, cold treatment chambers;


- A variety of industrial and laboratory drying ovens;



- Testing temperature and climatic equipment;


- Muffle and chamber furnaces;



- Various equipment under the order according to the customer's specifications.
