Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing

Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing
Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing

Large Image :  Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing

Product Details:
Place of Origin: Guangdong,China
Brand Name: GSKA
Certification: CE SGS ROHS UL
Model Number: GSA-X21
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiate
Packaging Details: The outer packing is first packed with foam plastic, and then reinforced with strong wooden cases.
Delivery Time: 15-30working days after received deposit
Payment Terms: L/C, T/T,
Supply Ability: 150 Set / Sets per Month

Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing

Description
Warranty: 1 Year Place Of Origin: Guangdong, China
Product Name: Xenon Test Chamber External Dimension: 1220mm*1200*2050mm
Lamp Rated Life: 2000h Weight: 500Kg
Brand: GSKA Light Source: One 6.5 KW Water-cooled Long Arc Xenon Lamp
High Light:

Temperature Test Chamber

,

Climate Test Chamber

Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing



product presentation:



The Xenon Chamber is a rotary type that meets the requirementsXenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing 0

of all domestic and foreign test standards. It adopts a high-power

precision water-cooled xenon lamp of 6.5KW, and the exposure

area reaches 6500cm. The Xenon light source and filter imported

from the United States are used to simulate the full spectrum of

sunlight more realistically. The stable light source ensures the

comparability and neproducibility of the test data.



Exposure Area Up To 6500cm²

It can expose 63 to 65 standard samples of 150mm×70mm at

a time. The automatic rotating three-layer drum-shaped sample

rack ensures consistent test conditions for all exposed samples.Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing 1


Imported Light Sources and Filters
Adopt imported 6.5KW water-cooled long arc xenon lamp and
imported filter from the United States. It can fully simulate the
indoor or outdoor solar spectrum, and the lamp has a lifespan
of up to 2000 hours, in line with intemational test standards.

Irradiance Self-calibrationUsers
can calibrate the irradiance by themselves. Through the irradiance
meter, just enter the value read from the calibrator, and then click
OK to automatically complete the entire calibration process.

Newly Upgraded Inner Chamber
The new stainless steel sandwich liner design will avoid rust and leak,
and at the same time effectively prevent the water vapor in the work
room from penetrating into the electrical part and damaging the
electronic components.

Spray System
The spray system is designed with 2 groups of 6 nozzles, one group
on the front and one on the back of the rotating sample frame; it is
controlled by Siemens PLC program, and the spray time can be
arbitrarily set in the program.

Specification

Model
GSA-X21
Light Source
One 6.5 KW water-cooled long arc xenon lamp
Lamp life
2000 hours
Filter
Original ATLAS filter; fully simulates the indoor or outdoor solar spectrum
Effective Exposure Area
6500 cm2 (63~65 pieces of standard samples of 150mm×70mm can be exposed to the sun at a time)
Irradiance Monitoring Point
340nm,420nm,300nm~400nm,300nm~800nm
Operation Room Temperature Adjustable Range
Chamber Temperature~70℃ (dark)
Black Panel/Black Scale Temperature Adjustable Range
BPT:Chamber Temperature~110℃;BST:Chamber Temperature~120℃

Xenon Arc Accelerated Aging Test Chamber For Laboratory Material Testing 2

FAQ

1. who are we?

  • We were founded in 1995

    Our company is devoted to the development and application of envrionmental test chambers.We provide chamber for
  •
  • simulating indoor and outdoor solar spectrum, polar cold, extreme heat, humidity, altitude, shock & vibration, water-proof IPX1~9K, dust test, salt
  •
  • spraying test and etc.Enable manufacturers to validate their products,ensuring they are resistant to temperature, humidity, light,rain,altitude, shock
  •
  • & vibration, water-proof IPX1~9K, dust etc.

2. how can we guarantee quality?

All of our climatic test chambers have passed ISO9001:2015 and ISO14001:2015 certifications. Always provide 9 point inspection report before

shipment;

3.what can you buy from us?

Environmental Chamber, Altheletic Training Room,Weathering Resistance Aging Chamber,Aging Machine,Aging Tester,Aging Equipment

4. why should you buy from us not from other suppliers?

our company was established at 1995 with more than 20+ years experience. Our product passed CE and ISO Certification with customer covered

moer than 70+coutries .

5. what services can we provide?

Accepted Delivery Terms: FOB,CIF,EXW,FCA,DDP,DDU,DAF; Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;

Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union,Cash; Language

Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Italian
