Product Details:
|
| Warranty: | 1 Year | Working Volume: | 22.5L |
|---|---|---|---|
| Usage: | Stability Temperature Humidity Test | Temp. Range: | -40 ~ +150℃ |
| Certificate: | CE | Test Hole: | D50mm,2pcs |
| Brand: | GSKA | Place Of Origin: | Donggaun,china |
| High Light: | 22.5L Climatic Test Chamber,Benchtop Temperature Humidity Test Chamber |
||
Mini Climatic Test Chamber 22.5L Benchtop Temperature Humidity Test Chamber
Benchtop Climatic Chamber Product applications:
Mini temperature and humidity test chamber, also named as benchtop climatic chamber is widely used in scientific research, research institutes, quality inspection institutes and other industries to do warm and humid heat tests of electronic and electrical products, materials, parts, equipment, etc., alternating heat test and constant temperature test, etc. Also could do high and low temperature routine tests, low temperature storage, in order to evaluate the performance of the sample under given environmental conditions.
Benchtop Climatic Chamber Product Product Positioning:
Apply to aerospace, aviation, electronics, automotive, battery and other products and quality inspection institutes, research institutes, universities and other test units, providing virtual space to simulate the real environment, verify product inspection, research and development results, test chamber is a powerful assistant to shorten the development cycle and improve product quality and reliability.
Benchtop Climatic Chamber Product technical specification:
| Model | GSK-22-CC |
| Temperature range | -40℃～150℃ |
| Temperature fluctuation | ±0.5℃ |
| Cooling rate | 150.0℃～25.0℃ Cooling rate 2.0～3.0℃/min 25.0℃～-40.0℃ Cooling rate 1.0～2.0℃/min -40.0℃～60.0℃ Cooling rate0.7～1.5℃/min |
| Heating rate | -60.0℃～150.0℃ Within about 60 minutes 3.0～5.0℃/min |
| Temperature uniformity | ±1.0℃ (-40.0℃～100.0℃) |
| ±1.5℃ (100.1℃～180.0℃or-40.0℃～-60.0℃) | |
| Humidity range | 20.0%RH～98.0%RH |
| Humidity fluctuation | ±1.0% RH |
| Humidity uniformity | ±2.0％RH |
| Internal material | SUS304 stainless steel(1.2mm) |
| External material | cold-rolled plate(1.2mm),powder coating |
| Heat insulation | polyurethane foam(100mm)+glass wool(10mm) |
| Fan | Centrifugal fan(Impeller Fan) |
| Refrigeration compressor | hermetic compressor(Tecumseh) |
| Cooling mode | air cooling |
| Refrigerant | R404A,R23 |
| Evaporator | finned-tube exchanger |
| Heater | nickel chrome strip heater |
| Humidifier | Steam Humidifier |
| Interior(mm) W*H*D | 300 X 300 X 250 22.5L |
| Exterior(mm) W*H*D | 480x835x990 |
| Weight | 95kg |
| Working Temperature | +5 ~ 35℃ |
| Power supply | 220V/AC 50/60Hz 12A |
| Controller |
Standard: SANWOOD |
FAQ:
1. Are a manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
A:-Yes, we are manufacturer
Chamber/Equipment/Machine/Cabinet . Every machine from our factory has a 12 months product warranty.If your machine doesn’t work, you can
send E-mail to us and we will try our best to find the problem by email or video chat if neccesary. After confirmation of the problem, we can send
you new spare parts or provide on-site repair.
2. What’s the delivery term?
A: -If there is no stock, normally, the delivery time is 15-25 working days after deposit receipt. If you are in urgent need, we can consider making a
special arrangement for you.
3. Do you accept customization service? Can I have my logo on the machine?
A:-Yes, of course. We can not only offer standard machines, but also customized
machines according to your requirements. And we can also put your logo on the machine
4. what about the products' quality?
A:-Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national
authoritative third-party inspection agency.
5.what about the packing of equipment?
A:-We use Standard Export Plywood Case to Protect it from rust during the long time shipping with the plastic film and protect its corners with the
foam.
