Product Details:
|
| Power Consumption: | 0.5 KVA | Model: | GSA-574T |
|---|---|---|---|
| Power: | Electronic | Maximum Load: | 100kg |
| Warranty: | 1year | Weight: | 45kg |
| Measurement Accuracy: | ±1.0% | Brand Name: | GSKA |
| Highlight: | 100kg Universal Tensile Testing Machine,OBM Universal Tensile Testing Machine,ODM Tensile Testing Machines |
||
Universal Tensile Metal Materials Testing Machine 100kg For Sale
product presentation:
|
item
|
value
|
|
Warranty
|
1yaer
|
|
Certification
|
CE
|
|
Customized support
|
OEM, ODM, OBM
|
|
Place of Origin
|
China
|
|
Power
|
Electronic
|
|
Maximum load
|
100kg
|
|
Force unit
|
N,KN,Kgf,Lbf
|
|
Power consumption
|
0.5 kVA
|
|
Power source
|
220 VAC, 50/60 Hz
|
|
Volume
|
57×47×120cm
|
|
Weight
|
70kg
|
|
Effective width of test
|
120 mm
|
|
Test stroke (including fixture)
|
800 mm
|
|
Measurement Accuracy
|
±1.0%
|
|
control mode
|
Computer software sets speed, sets load breaking (breaking), running
time and other control methods
|
|||
|
Manual operation box
|
It is convenient to calibrate and position the specimens when loading and
holding them. It can automatically determine the material breaking,
crushing, and stop the machine. It can be set to return
automatically
|
|||
|
Curve type
|
Load - displacement, load - time, displacement - time.
Stress - strain, strain - time, stress - time. Curve vertical and horizontal coordinates can be set arbitrarily. |
|||
|
Available test data
|
Maximum strength, minimum strength, fracture value, upper and lower
yield strength, tensile strength, compressive strength,
modulus of elasticity, elongation, maximum, minimum, mean value, etc.
It has multiple protection such as overload, overcurrent,
overvoltage, undervoltage, overspeed and travel. |
|||
|
Load sensing
|
High precision pressure and tension actuator,(multiple sensors can be
installed at the same time - optional)
|
|||
|
Test speed range
|
1～400mm/min
|
|||
FQA:
Q1: What's your guarantee?
A: The product warranty is 12 months, but lifetime service. Non-consumable parts will be provided free of charge in the event of performance
failure due to non-human damage within 12 months.
Q2: How to provide video?
A:Yes. If needed, our engineers will record a special video for you.
Q3:Is your company a trading company or a factory?
A: Yes, we are manufacturing plant and trade (integration). 10 years focused on the field of test instruments. 5 years of export experience, warmly welcome to visit the factory.
Q4: After the order is placed, when will it be shipped?
A: Usually about 15-30 days. If we have stock, we can arrange shipment within 15 days. Please note that our production lead time depends on the specific project and the number of projects.
Q5:What about after-sales service and product quality?
A:The warranty is 12 months. After warranty, professional after-sales service team will provide perfect technical support. Help customers to solve the problems encountered in the process of use, professional and timely handling problems and complaints. Each instrument must be inspected and tested for 100% quality at the time of shipment and delivery. Product use training, each of our products provide video training to show you how to install and operate. Engineers will go abroad for training and maintenance.
Q6:How about the packaging of the equipment?
A: Before the machine is put into the standard export wooden box, the bubble film is covered first, which not only has good shock absorption and impact resistance, but also has the advantages of non-toxic, odorless, moisture-proof corrosion and good transparency.
