Product Details:
|
| Display: | Treadmill Test Machine | Production Capacity: | 1000 Sets/ Month |
|---|---|---|---|
| Cooling: | Air Cooling | Weight: | 0-100Kg |
| Test Width: | 550kg | Power Source: | AC220V |
| Power: | Electronic | Warranty: | 1 Year |
| High Light: | Vibration Tester,Vibration Test Machine |
||
Motorcycle brake testing machine bicycle comprehensive testing machine
a. It is possible to set the torque resistance T1 of the rollers of the driving equipment: 0-1000kg-cm and calculate the output torque resistance T2 of the test vehicle.
b. It can detect and record the mileage.
c. It can detect the voltage V/current A/power W input by the battery and record the ampere hour (A.HR).
d. It can detect and record the number of tire revolutions of the test drive: N2 (RPM) and the number of revolutions of the test roller N1 (RPM).
e. It can detect and record the horsepower P of the test vehicle (P=0.01T2 X 9.81 X 2 XII XN2/60).
f. The transmission speed η=P/W of the test vehicle can be calculated and recorded.
g. Can calculate and record battery usage: ampere hour (A.HR).
h. It can be set to stop the test when the battery voltage is lower than the set value.
| Torque sensor capacity | 0-100N.M |
| Torsion Sensor Nonlinearity | ±0.1%--±0.3%(F·S) |
| Torque Transducer Repeatability | ±0.1%--±0.2%(F·S) |
| Torque Sensor Accuracy | ±0.2%--±0.5%(F·S) |
| Torque sensor ambient temperature | 0ºC--40ºC |
| Torque Transducer Frequency Response | 100μs |
| The output voltage | 0-12V, load current <10mA |
| Sensor | SETECH |
| Speed regulation range of speed regulating motor | 0-110RPM |
| Motor | DL Dongling or Zhangyi or Tai'an frequency conversion control |
| Acquisition System | American NI capture card |
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
