Product Details:
|
| Warranty: | 1 Year | Place Of Origin: | Guangdong,China |
|---|---|---|---|
| Spray Method: | Continuous Spraying | Power: | Electronic |
| Spray Volume: | 1.0~2.0ml/80cm2/h | PH: | 6.5~7.2 3.0~3.2 |
| Uses: | Electronic Salt Fog Testing Cabinet | Certification: | CE SGS ROHS UL |
| Highlight: | Thermal Test Chamber,Environmental Test Chamber |
||
Spray Volume 1.0~2.0ml/80cm2/H Salt Spray Chamber For Factories, Laboratories
product presentation:
The salt spray test chamber is a climate simulation device that tests the corrosion of electronic equipment, metallic material, as well as some surface treatment--coating, galvanizing, organic/inorganic coating, anodizing treatment, rust-proof oil coating, etc. Performance indicators in line with requirements of GB / T5170.8 Electrical and Electronic Products, Environmental Testing Equipment, the Basic Parameters of the Test Method. The salt spray corrosion test chamber according to GB / T2423.17 Electronic and Electrical Products Basic Environmental Test Procedures Test: Salt Spray Test Method for neutral salt spray test can also be used for acetic acid salt test.
|
Model
|
GSA-X56
|
GSA-X57
|
GSA-X58 |
GSA-X59
|
|
Inner size (cm)
|
60x45x40
|
90x60x50
|
120x80x50
|
160x100x50
|
|
External size(cm)
|
107x60x118
|
141x88x128
|
190x110x140
|
230x120x140
|
|
Inside temp
|
Brine test method(NSS ACSS)50°C±1°C Corrosion resistance test method.
|
|||
|
Brine temp
|
35°C±1°C 50°C±1°C
|
|||
|
Test chamber volume
|
108L
|
270L
|
480L
|
800L
|
|
Brine chamber volume
|
15L
|
25L
|
40L
|
40L
|
|
Spray method
|
Programmable spray (including the continuous spray interrupted spray)
|
|||
|
Spray volume
|
1.0~2.0ml/80cm2/h (Collect at least 16 hours, the average)
|
|||
|
PH
|
6.5~7.2 or 3.0~3.2
|
|||
|
Test room relative humidity
|
85%RH or more
|
|||
|
Compressed air pressure
|
1.00±0.01kgf/cm2
|
|||
