Product Details:
|
| Warrany: | 1year | Place Of Origin: | Dongguan, China |
|---|---|---|---|
| Voltage AC: | 220V | Max Working Temperature: | 1200℃ |
| Model Number: | GS-B1027 | Heating Power: | 9KW |
| Heating Rate: | 1-20℃/min, Adjustable | Suggested Heating Rate: | 5-8℃/min |
| Highlight: | Vacuum Atmosphere Furnace,Vacuum Sintering Furnace |
||
Vacuum atmosphere furnace is a kind of high temperature experiment equipment, mainly used in inert atmosphere or vacuum environment for high temperature treatment, sintering, heat treatment, annealing, REDOX experiment and production process. It can control the atmosphere of the sample at high temperature to meet different experimental requirements.
Vacuum atmosphere furnace has been widely used in material science, chemistry, electronic engineering, new energy, aerospace and other fields. For example, in the field of materials science, vacuum atmosphere furnaces can be used to prepare high purity materials, functional ceramics, nanomaterials, etc. In the field of electronic engineering, vacuum atmosphere furnace can be used to produce semiconductor devices, photovoltaic cells, etc. In the field of aerospace, vacuum atmosphere furnaces can be used to prepare high temperature materials such as aeroengine components.
|
Model |
GS-B1027 |
|
Voltage AC |
220V |
|
Heating power |
9KW |
|
Furnace inner chamber size |
400*300*300mm (depth*width*height) |
|
Max working temperature |
1200℃ |
| Long-term working temperature | ≤ 1100℃ |
| Heating rate | 1-20℃/min, adjustable |
| Suggested heating rate | 5-8℃/min |
| Temperature control precision | ±1℃ |
| Atmosphere | Nitrogen, Argon, etc. |
| Vacuum system (optional) | Mechanical pump, 2000PA |
| Control method | Automatic control system is adopted, which can run automatically from room temperature to set temperature. Silicon controlled system, temperature control system modular design, simple structure, convenient maintenance. Imported thyristor control, can freely set constant temperature and heat preservation curve, no interference switching function, the instrument has temperature correction and compensation function. |
| Number of programmed curve segments | 31 segments are adjustable to reduce unnecessary troubles caused by artificial settings. |
| Display accuracy | ±1℃ |
| Digital display | Measuring temperature and setting temperature both display |
| Control characteristics | The modular structure of control system, long life design of key parts of equipment, simple and reliable process, good stability and high precision. |
| Air cooling system | The fan impeller is mounted directly on the bottom of the double furnace shell and assembled with the control system. When the sintering furnace is heated, air cooling can reduce the surface temperature of the furnace shell and protect the heat of the electric appliance, and the personnel operation is safer and the efficiency is improved. |
| Shell | The furnace shell is welded by steel plate and profile, and the outer casing is equipped with a removable protective plate. The protective plate is electrostatically sprayed and painted. Fine workmanship and beautiful appearance. |
| Furnace structure |
Double-layer furnace shell structure, air-cooled circulation, reducing the temperature of the shell. Shell surface temperature < 60 degrees. The surface of the inner furnace is coated with a high-temperature alumina coating to increase the heating efficiency of the equipment and to extend the life of the instrument. |
| Energy saving performance | Light weight, fast heating, energy saving more than 50%, save time and labor. |
| Parts | Crucible tongs, high temperature gloves |
FAQ:
Q1: How to order?
A: Please send us your purchase order by email or call us sales, or we can make the proforma invoice underl your request.We need to know the following information for your order before sending your Pl.1)Product information-quantity, specification(size, material, technological if needed and packing requirements etc.)2)Delivery time required.3)Shipping information-company name, street address, phone number, destination sea port4)Forwarder's contact details if there's any in china.
Q2: How to control quality?
A, All the raw materials by IQC (Incoming Quality Control) before launch whole process into the process after the screening.B, Process each link in the process of IPQC(Input Process Quality Control)patrol inspection.C, After finished by QC full inspection before packing into the next process packing.D, OQC before shipment for each slipper to do full inspection.
Q3: How can I install and operate the machine by myself?
A: Our system R&D based on integrated development view. when you get the machine, just need to connect it with the electrical power, then machine can be working. because the English software were installed in this machine. what you need to do is only leaning the software usage, and the complete English user manual will bel coning to you with the machine.
Q4: How to get technical support after purchasing?
A: Our factory provide online technical support in English, you can easy catch us online by SKYPE,WECHAT, WAHTSAPP or Email, if you need any remote assistant support, then we will support you though TeamViewer software.
Q5:What certificates do you have?
A: Since Europe and America are our main markets, all of our products are with CE /FCC compliant. For some models, the certificates are already available. For other models, we will need your assistance to apply the certificates.
Q6:What's the warranty for the items?
A: We are very confident in our products, and we pack them very well, so usually you will receive your order inl good condition. any quality issue, we will deal with it immediately.Warranty for equipment is a year (12 months), If the equipment parts are damaged due to non-human factors within one year, we will provide replacement partsl free of charge.
