120KW Vacuum Resistance Furnace For Stainless Steel Metal Materials Heat Treatment

120KW Vacuum Resistance Furnace For  Stainless Steel Metal Materials Heat Treatment
120KW Vacuum Resistance Furnace For  Stainless Steel Metal Materials Heat Treatment 120KW Vacuum Resistance Furnace For  Stainless Steel Metal Materials Heat Treatment 120KW Vacuum Resistance Furnace For  Stainless Steel Metal Materials Heat Treatment

Large Image :  120KW Vacuum Resistance Furnace For Stainless Steel Metal Materials Heat Treatment

Product Details:
Place of Origin: Donggaun,china
Brand Name: GSKA
Certification: CE SGS ROHS UL
Model Number: GS1025
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiate
Packaging Details: Export package
Delivery Time: 10-60days after confirmed payment or by contract stipulation
Payment Terms: L/C, T/T
Supply Ability: 160 Set / Sets per Month

120KW Vacuum Resistance Furnace For Stainless Steel Metal Materials Heat Treatment

Description
Place Of Origin: Donggaun,china Type: Resistance Furnace
Core Components: PLC, Pump, Heating Element, Furnace Shell Voltage: AC380V50Hz, AC380V50Hz
Power (kW): 120 Key Selling Points: Competitive Price
Pressure Rise Rate: 0.67Pa/h Loading Capacity: Loading Capacity
Highlight:

Vacuum Atmosphere Furnace

,

Vacuum Sintering Furnace

120KW Vacuum Resistance Furnace For Stainless Steel Metal Materials Heat Treatment

product presentation with vacuum resistance furnace :

This vacuum resistance furnace is mainly used for vacuum heat treatment and vacuum post welding heat treatment of heat-resistant steel, stainless steel, and structural steel parts. Used to eliminate machining stress on precision parts of finished product size and adopt residual stress stabilization treatment. It is used for finished product dimensions. Precision forging, final heat treatment of precision forgings, etc., can also be applied to aging annealing, oil quenching, air cooling and other heat treatment processes of various materials such as high-speed steel, high alloy tool steel, precision mechanical parts, etc. After heating, insulation, and cooling the parts under working vacuum, stainless steel, structural steel, and other materials will be bright and free from oxidation, and the surface of the parts will not have any carburization phenomenon, reducing element consumption.

Technical parameters of vacuum resistance  furnace :



Place of Origin Donggaun,china
Type Resistance Furnace
Core Components PLC, Pump, Heating Element, Furnace Shell
Voltage AC380V50Hz, AC380V50Hz
Power (kW) 120
Key Selling Points Competitive Price
Pressure rise rate 0.67Pa/h
Loading capacity Loading capacity
Loading capacity 1200kg
Weight (T) 1.5 T
Ultimate vacuum 6*10(-3)Pa





/photo/o2-machines/editor/vacuum resistance furnace

/photo/o2-machines/editor/120KW vacuum resistance furnace

/photo/o2-machines/editor/vacuum resistance furnace



FAQ :



Q1: How is your company's product after-sales service system?



A: We have professional pre-sales and after-sales departments and



can respond to you within 8 hours to resolve any technical issues.


Q2: How about the quality guarantee period?


A: 1 years, exclude irrationally operating and consumable parts.


Q3: How about your products quality?


A: CE certification available and twice test before shipping.


Q4: What's your delivery time?


A: Conventional model needs 30 days. 60 days for customized products


Q5: Are you a manufacturer or a trading company?


A: We are a factory with 10 years experience in the field.



Q6: What is your core competitiveness?



A:We not only provide quenching furnaces, but also heat treatment processes.
