Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons

Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons
Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons

Large Image :  Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons

Product Details:
Place of Origin: DongGuan China
Brand Name: GSKA
Certification: CE ISO
Model Number: Vacuum hot press furnace
Payment & Shipping Terms:
Minimum Order Quantity: Negotiate
Price: Negotiate
Packaging Details: Export package
Delivery Time: 10-60days after confirmed payment or by contract stipulation
Payment Terms: T/T, Western Union, MoneyGram etc
Supply Ability: 100 Set / Sets per Month

Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons

Description
Core Components: PLC Voltage: 380V
Max Temperature: 500C - 1300C (custom Made) Temperature Unifor: ±5℃
Heating Method: Resistance, Induction Heater: Mo Belt, Tungsten, Graphite, SiMo, SiC
Applicable Industries: Manufacturing Plant, Foundry PLC Controller: SIEMENS, MITSUBISHI, LG
Highlight:

Vacuum Brazing Furnace

,

Box Type Furnace

Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons



Products Description:


Vacuum gas quenching furnace is mainly used for cool work & hot work steel, high speed steel, tool steel material vacuum quenching, tempering and solution-ageing process. And it is divided into horizontal and vertical types. The vertical type vacuumgas quenching furnace is especially suitable for the vacuum gas quenching process of large workpieces with easy deformation such as long rod-shaped parts, shafts and plate parts. The workpieces can keep bright and minimal deformation after heat treatment.

The followings are the technical characteristics:

1. The heating element is graphite (Customizable), the thermal insulation layer is the thermal insulation structure of the
composite carbon felt and the soft felt, which can ensure the temperature uniformity.

2. The internal use of the overall telescopic structure telescopic car, with frequency control to ensure smooth delivery of
materials, transfer time is short.

3. Quenching Oil Hot oil pump with heat pump and heat exchanger outside the cooling, quenching oil cooling faster, higher
efficiency.

4. Built-in heat exchanger and forced air circulation cooling mode, jet gas uniform and flow, cooling speed.

5. Dual choice of oil mixing and oil jet cooling method for different types of parts, small deformation of the workpiece.

6. The furnace is equipped with temperature, pressure, water pressure, vacuum and other interlocking features, with a high
degreeof safety protection and prevention functions.

7. With remote control operation, remote fault diagnosis and remote program updates and other functions.

Product Paramenters:

Model
Working size
(mm)
Ultimate pressure
(pa)
Pressure rising rate(pa/h)
Loading capacity(kg)
Cooling gas pressure(bar)
GA20
200*200*200
4*10-¹~6.7*10-³
0.67
50
6/10/15/20
GA30
300*300*500
4*10-¹~6.7*10-³
0.67
100
6/10/15/20
GA40
400*400*600
4*10-¹~6.7*10-³
0.67
200
6/10/15/20
GA50
500*500*700
4*10-¹~6.7*10-³
0.67
300
6/10/15/20
GA60
600*600*900
4*10-¹~6.7*10-³
0.67
500
6/10/15/20
GA70
700*700*1000
4*10-¹~6.7*10-³
0.67
700
6/10/15/20
GA80
800*800*1200
4*10-¹~6.7*10-³
0.67
1000
6/10/15/20
GA50
Ø500*700(vertical)
4*10-¹~6.7*10-³
0.67
300
6/10/15/20
GA70
Ø700*900(vertical)
4*10-¹~6.7*10-³
0.67
500
6/10/15/20
GA100
Ø1000*1000(vertical)
4*10-¹~6.7*10-³
0.67
800
6/10/15/20
GA120
Ø1200*1000(vertical)
4*10-¹~6.7*10-³
0.67
1000
6/10/15/20
Max temperature:1320℃ , Temprtature unifromity:±5℃

Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons 0Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons 1Carbide Heating Vacuum Hot Pressing Sintering Furnace 300 Tons 2



Advantage:


Ø 24 hours online


Ø 35 years experiences


Ø Sample chamber of each model


Ø Best price, fast delivery


Ø OEM,ODM


Ø Oversea offices


Ø Own import and export business license


Ø ISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
