Product Details:
|
| Temp. Control: | Room Temperature | Heating Rate: | +20℃~150℃ |
|---|---|---|---|
| Temperature Deviation: | Less Than Or Equal To±1.5℃ | Power: | Electronic |
| Test Voltage: | 500A, 1000A Two Ranges | Short Circuit Time: | 0~9999H/MIN/S |
| Brand: | GSKA | Standard: | GB/IEC/EN/UN38.3/UL |
| High Light: | Environmental Humidity Chamber,Humidity Test Chamber |
||
Laboratory Battery Testing Equipment Heavy Weight Impact Testing Machine
Equipment Overview:
Application: It is used to simulate all kinds of batteries suffering from external impact during using, transportation and storage.
Test Principle:
The test sample battery placed on the same plane, a rod cross with a diameter of 15.8 ± 0.2mm (5 / 8Iinch) Cross cross placed in the center of the sample. One 9.1kg or 10kgHeavy objects fall from a certain height(610mm or1000mm)to the sample. Cylindrical or square battery when receiving impact test, the longitudinal axis should parallel to the plane, perpendicular to the longitudinal axis of the steel column. The maximum axis of square batteries is perpendicular to the steel column, and the maximum surface is perpendicular to the impact direction, and each battery only accepts an impact test.
Structure:
One machine structure, the door uses explosion-proof lock + explosion-proof chain
Technical Parameters:
| Control and Operation | PLC touch screen intelligent control system, with remote control device |
| Dimensions |
Inner box WDH=500×300×800mm,304 stainless steel Outer box WDH=940×780×1620mm,A3 Cold rolled steel plate paint,thickness1.0mm Visual window WH=390×360,20mm Tempered explosion-proof glass + protective steel network double-layer protection Exhaust port 150mm, on the upper of the back box, Visual window WH=390×360,20mm |
| Lifting method | Electric |
| Upper and down impact surface | Steel Plate |
| Test weight | 9.1kg±0.1kg |
| Falling Height | 0~770mm(Adjustable),(Default) 610±25mm |
| Bar Diameter | 15.8 ±0.2mm |
| USB | With USB interface, test data can be exported |
| Safety Protection System | Explosion-proof relief device, exhaustive device, fire extinguishing system, electronic door lock system, safe stop switch. |
| Optional Purchase | Temperature capture, voltage collection system, video surveillance system |
Advantage:
Ø 24 hours online
Ø 35 years experiences
Ø Sample chamber of each model
Ø Best price, fast delivery
Ø OEM,ODM
Ø Oversea offices
Ø Own import and export business license
Ø ISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
