Product Details:
|
| Place Of Origin: | Dongguan China | Steam Pressure(MPa): | 0.2-0.8 |
|---|---|---|---|
| Drying Temperature(ºC): | 50-150 | Number Of Fans: | 14 |
| Brand Name: | GSKA | The Fuel: | Gas,Diesel,Wood Chips,Electricity,Steam |
| Power(Kw): | 30.8-56 | Evaporation Capacity(kg/h20/h): | 150-450 |
| High Light: | Environmental Humidity Chamber,Humidity Test Chamber |
||
Industrial Tunnel Conveyor Belt Dryer Food Dewatering Machine Fish Drying Oven
Monitoring method:
In order to obtain accurate and reliable parameters, which can reflect the actual situation of the furnace, but can not be too complicated, and the monitoring time can not be too long, the regulation of monitoring method is particularly important. We stipulate that the monitoring test shall be carried out under normal production conditions, and the monitoring cycle shall be the whole process of 1 furnace. In drafting, we also consider to have higher accuracy, and for three furnace monitoring period, but after for advice, think sand drying time is long, and 3 furnace furnace products quantity also is often difficult to achieve in a short time, generally is field testing and monitoring, can't take a long time waiting, so the more realistic or 1 furnace as monitoring cycle.
Instrument selection and use:
The instrument must be within the validity period of verification and marked with CMC mark. The accuracy of the weighing instrument is above level 1.5, each weighing must be between 75% ~ 95% of the measuring range; For fluid fuel, the flowmeter is used for testing. Due to the low accuracy of the flowmeter, the accuracy of the flowmeter is selected to be above level 2.5. The maximum fuel flow rate during the operation of the drying furnace should be between 75% and 95% of the maximum instantaneous flow rate of the flowmeter.
Advantages:
1. The drying machine with fully automatic feeding and discharging;
2. The fast-drying system, the drying machine not only according to heat to dry but also according to strong air.
3. Drying machine with the movable door, easy to clean.
4. More durable, corrosion-resistant; The temperature and speed of the dryer can control by the control panel.
Application Range:
It is not only can dry the Hemp Leaves, but also is widely used in food, vegetable, fruit, medicinal herbs, and other material. The Hemp Multi-layers Belt dryer is used for mass production of continuous drying equipment for the drying of the sheet, strip pellet material with better ventilation property, especially for the materials cannot bear high temperatures such as dehydrated vegetables, Chinese herbal pieces of high moisture content. Belt driers have many advantages, such as a fast-drying rate, high evaporation strength, good product quality; cake type of paste materials, wet granulation can also be dried.
Specifications:
| Model | GSKA-1 | GSKA-2 | GSKA-3 | GSKA-4 | GSKA-5 | GSKA-6 |
| Drying Unit | 4*3 | 5*3 | 4*3 | 5*3 | 4*3 | 5*3 |
| Mesh Belt(m) | 1.2 | 1.6 | 2 | |||
| Drying Length(m) | 8*3 | 10*3 | 8*3 | 10*3 | 8*3 | 10*3 |
| Material Thickness(mm) | 10-80 | |||||
| Drying Temperature(ºC) | 50-150 | |||||
| Steam Pressure(MPa) | 0.2-0.8 | |||||
| Heat exchange area(m²) | 816 | 1020 | 1056 | 1320 | 1344 | 1680 |
| Evaporation Capacity(kg/h20/h) | 150-450 | 240-650 | 220-600 | 280-750 | 300-600 | 350-850 |
| Number of fans | 14 | 17 | 14 | 17 | 14 | 17 |
| Power(kw) | 30.8 | 32.6 | 30.8 | 32.6 | 54.2 | 56 |
| Total Power(kw) | 35.3 | 37.1 | 35.3 | 37.1 | 58.7 | 60.5 |
| Dimensions(L*W*H) | 9.77 | 11.7 | 9.77 | 11.77 | 9.77 | 11.77 |
| 2.2 | 2.2 | 2.6 | 2.6 | 3.06 | 3.06 | |
| 4.7 | 4.7 | 4.7 | 4.7 | 4.9 | 4.9 | |
| Weight(kg) | 4800*3 | 5780*3 | 5400*3 | 6550*3 | 6350*3 | 7800*3 |
About Us Pre-sale services:
Act as a good advisor and assistant of clients; enable them to get rich and competitive
from the returns of their investment.
1) Select a suitable equipment model.
2) Design and manufacture products according to clients' special requirements.
3) Train technical personnel for clients.
4) Professional suggestion for the customer.
