Product Details:
|
| Temp.&humidity Uniformity: | ±1℃; ±2%RH | Temperature Fluctuation: | ±1.0℃ |
|---|---|---|---|
| Customized Support: | OEM | Condenser: | Water-cooled Condensing Agent |
| Impact Recovery Time: | (-40)℃~(+150)℃≤5min | Temperature Uniformity: | ±2.0℃ |
| Power: | 220V , 50Hz | Keyword: | Thermal Shock Chamber |
| High Light: | Temperature Test Chamber,Climate Test Chamber |
||
Waterproof SUS304 Shock Test Chamber , 10Kg Environmental Testing Equipment
Features:
The Thermal Shock Test Machine is divided into three chambers(three zones): the high temperature chamer,the low temperature chamber and the testing chamber
Reasonable structure, cooling speed quickly.
Import of refrigeration units, the main parts are imported international brands, the whole system is equipped with multiple protection devices, to improve reliability.
clever duct structure, small temperature deviation.
Door with observation window, the test specimen can be easily observed state.
Mechanical sheet metal structure:
All functions are controlled by computer, it is self-developed software, and has a good operation interface, which makes the user's operation and monitoring more simple and intuitive. You can set the time and parameters on the screen to switch between cooling, heating, and blue transfer, and press the set button. The setting is performed automatically.
The cold box and the hot box are independently controlled, and the box doors are independent of each other, which expands the use range of the test box (one box for three purposes).
The thermal insulation effect of the product can be fully guaranteed.
The door of the test chamber is interlocked with the circulating fan and the blue drive to protect the safety of the operator. Once the door is opened, the power supply of the circulating fan and the blue drive will be automatically cut off.
There is a standard lead hole tube on the top of the box, which is convenient for users to introduce sensor lines, detection cables and other types of leads into the box.
Application:
For electrical, electronics and machine parts to cold test, the temperature gradient through rapid changes in conditions or the suitability test. Especially suitable for electrical and electronic products, environmental stress screening options (ESS) test.
| Temperature range | A.high-temperature : +60 degree to +150 degree |
| B.low-temperature : -10 degree to -40 degree | |
| Control temperature | ±2 degree |
| resolution | 0.01 degree |
| Heating time at high-temperature region | From RT to 150 about 35min (RT is from 5 degree to 30 degree). |
| Cooling time at low-temperature region | From RT to -40 degree about 50min (RT is from 5 degree to 30 degree) |
| Moving time and temperature recover time | A. testing bastet moving from high-temperature to low-temperature spend 10sec |
| B.after exchanging the temperature,the tempreature recovery time: 3min to 5min (Stabilization time ≥ 30min) | |
| Device noise | Below 75dB. |
| Weight | 10Kg |
| Testing region(hot and cold) | 50cm(W)*50cm(H)*50cm(D) |
| Outside size | 140cm(W)*180cm(H)*142cm(D) |
| Testing basket size | 30cm(W)*40cm(H)*30cm(D) |
| Inside material | SUS#304 Cold-Heat-resistant stainless steel |
| Outside material | SUS#304 Cold-Heat-resistant stainless steel |
| Insolution material | High-density glass wool and high strength PU foam insulation |
| Anti-sweat structure | insulation layer and door micro-thermal anti-sweat |
| Expansion | Heat reach 300 degree,cold reach -100 degree |
Service:
1. Device installation;
2. Equipment Operation Test Technology training;
3. Equipment Calibration;
4. Daily maintenance and maintenance of equipment
5 Free technical training for visiting factories
6 24-hour Online contact
7 Free software upgrades
