Product Details:
|
Usage: | UV Aging Test Chamber | Material: | Stainless Steel |
---|---|---|---|
Humidity Range: | ≥75%RH | Brand: | GSKA |
Keyword: | UV Weathering Test Chamber | Lamp Power: | 40W/Unit, 8PCS For Unit Chamber |
Air Pressure: | 86~ 106Kpa | Power: | Electronic |
High Light: | UV Weathering Test Chamber,Accelerated Weathering Chamber |
Power Supply380v 40w Uv Light Testing Equipment Waterproof Accelerated
Product description:
Accelerated Weather UV test machine is applicable for the sunlight resistant test of nonmetallic materials and aging test of artificial light sources. A variety of industrial products can make the reliability test, and this product can simulate the product in the sun, rain, humidity and dew conditions, including damage caused by bleaching, color, brightness down, powder, crack, blur, brittle, intensity decreased and oxidation.
Chamber Structure:
The inner bladder of the chamber is made of imported high-class stainless steel plate while the outer bladder is made of SUS 304 steel plate.
The heating mode adopts inner bladder trough type heating with its rapid temperature rise and even temperature distribution.
Specifications of Aging UV Test Chamber:
Product Name | UV Weathering Test Chamber | |
Internal dimensions (mm) | 450*1170*500 | 450*1170*500 |
Overall dimensions (mm) | 680*1300*1500 | 680*1300*1500 |
Capacity of test specimens | 48 pieces Individual specimen size is 75mm * 150mm | 48 pieces Individual specimen size is 75mm *150mm |
Controller | Programmable color display touch screen controller | Programmable color display touch screen controller |
Temperature range | Ambient~90℃ ±2℃ | Ambient~90℃ ±2℃ |
Humidity range | ≥95%R.H ±2%R.H |
≥95%R.H ±2%R.H
|
Black Panel Temperature | BPT 30~80℃ | BPT 30~80℃ |
Irradiation Source | Fluorescent UV lamps (8) - 40 W | Fluorescent UV lamps (8) - 40 W |
UV wavelength | 290 ~ 400nm | 290 ~ 400nm |
Irradiance Control | N/A | 0.3 ~ 20 W/㎡(340 nm / 313 nm) |
Water Spray | Spraying water | Spraying water |
Distance of Specimen and lamp | 50mm | 50mm |
Nominal power | 5000W | 5500W |
Power Supply | 380V 50HZ | 380V 50HZ |
Function:
1. Simulate the sun, rain spray and condensation resulting damage to test the materials by exposure to sunlight with moisture and temperature.
2. To get the results of damage after several days or weeks which is equal to expose to outside for a few months. The damages include fading, discoloration, brightness down, powder, crack, blur, brittle, strength decreases and oxidation.
3. Provide reference with testing data for improvement of existing materials, or to assess the impact of changes in product durability and other aspects.
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
