Can Be Equipped With Multiple Sensors Wire Tensile Testing Machine OEM

Can Be Equipped With Multiple Sensors Wire Tensile Testing Machine OEM
Can Be Equipped With Multiple Sensors Wire Tensile Testing Machine OEM Can Be Equipped With Multiple Sensors Wire Tensile Testing Machine OEM

Large Image :  Can Be Equipped With Multiple Sensors Wire Tensile Testing Machine OEM

Product Details:
Place of Origin: Guangdong,China
Brand Name: GSKA
Certification: CE
Model Number: Universal Tensile Testing Machine
Payment & Shipping Terms:
Minimum Order Quantity: negotiate
Price: negotiate
Packaging Details: The outer packing is first packed with foam plastic, and then reinforced with strong wooden cases.
Delivery Time: 15-20working days after received deposit
Payment Terms: L/C, T/T
Supply Ability: 150 Set / Sets per Month

Can Be Equipped With Multiple Sensors Wire Tensile Testing Machine OEM

Brand Name: GSKA Resolution: 1/1,000,000
Stoke: 650~1200mm Quality Certification: CE
Operation Method: Computer Control Induction Method: Precision Load Cell (sensor)
Material: Stainless Steel Speed: 0.01mm/min~500mm/min
High Light:

Tensile Test Equipment


Tensile Strength Tester

Can Be Equipped With Multiple Sensors Wire Tensile Testing Machine OEM


Matters needing attention:

One, tensile testing machine load, the pointer tremble or stop

1, clutch gear wear: need to repair or replace.

2, friction disk of the skin washer or spring wear: need to replace the skin washer or spring.

3. Control handle shift: Adjust the control handle to make it cooperate well with the tooth socket.

Two, replace the pendulum weight pointer does not return to zero

1, tensile testing machine installation is not level: use a level to adjust the level of the testing machine.

2, the pendulum is not vertical: only hang A weight. Adjust the balance weight to make it vertical.

Three, tensile testing machine pendulum back too fast or too slow

1. Improper placement of buffer valve gear position: adjust the buffer valve to the appropriate position.

2. Hydraulic oil viscosity is too low or too high: when the hydraulic oil viscosity is too low, the pendulum falls back quickly, and when the viscosity is high, it falls back slowly. Hydraulic oil of appropriate viscosity should be replaced.

3, buffer valve, oil pipe or hydraulic oil dirty: clean buffer valve, oil pipe. Replace the hydraulic fluid.

Four, tension testing machine pointer back to zero stagnation or unstable

1, pointer bearing, spindle bearing rust or oil: clean or replace the bearing.

2, tooth rod deformation or tooth rod and gear do not mesh: straightening tooth rod or cleaning, dressing gear, groove wheel and other transmission parts.

3, the buffer valve is dirty: clean the buffer valve.


Main Technical Parameter: Tensile Test Equipment:


Max capacity 5kg,10kg,25kg,50kg,100kg,250kg,500kg,1000kg,2000kg,5000kg(It is optional.) can be setting
Induction method : Precision load cell (sensor)
Max. Load Capacity : 5000kg
Force Resolution/Accuracy: ± 0.5%
Accuracy class : 0.5
Resolution: 1/1,000,000
Test width: 400mm(Standard specifications special specifications can be customized)
Test stroke : Max.700 mm( included the fixture)
Stroke Resolution: 0.01mm
Speed range: 0.001-20inches/min
Reference Machine Dimension: 800×530×1600mm (L*W*H) Support Customized
Power : 1 phase 220V 50/60Hz
Packing Standard Export plywood case
Force system servo drives + Servo motor + precision ball screw drive
Control system Mechanical transmission + TM2101 + Pulse Command and Control System control
Measurement and Control System TM2101 and control system; master controller uses the most advanced 32-bit ARM processor in the 21st century, the processing speed
of the Pentium-class common computer standards, compared to the traditional 8 yuan SCM control system overall performance greatly
improved, faster operation, control accuracy higher

Obtain data
The key components are used America's most stable and ultra-precision 24 yuan AD,
sampling rate of up to 2000 times / sec, can capture the power of instantaneous change process, the entire file, regardless of the
resolution of up to 1,000,000 indexing
Displacement Control: Displacement encoder count with four frequency technology
So that the displacement of four times
the resolution can up to 0.0005mm
Safety devices: 1. overload, emergency stop device
2. the upper and lower travel limit devices
3. the test is completed automatic shutdown device
Reference standard
ASTM D903, ASTM E8 CNS11888, JIS K6854, PSTC7 ASTM D903,GB/T16491CNS-11888,JIS K6854, PSTC-7 ,ASTM E4,ASTM D828,ASTM D882,ASTM,D1938,ASTM D 412 ,ISO 8339ASTM D3330,ASTM F88,ASTM F904,ISO 37,JIS P8113,QB/T 2358,QB/T 1130 , ISO 527 ,ISO 178 and other



Industry and functional characteristics:

1, metal tensile testing machine: metal material tensile strength, small elongation, need to configure metal punctuation extensiometer.

2, rubber tensile testing machine: rubber or elastomer elongation is relatively large, need to be attached with a large punctuation elongation device, at the same time the fixture design to consider the characteristics of rubber, can not slip. Can be added with O - ring fixture, tire industry fixture, etc.

3, plastic tensile testing machine: plastic tensile strength is bigger than rubber, elongation is big or small, and often to test three point bending test.

4, textile tensile testing machine: textile industry needs to test fabric peeling, piercing, tearing, single yarn tensile test, fixture and software is special.

5, paper tensile testing machine: paper needs to test tensile strength, ring compressive strength, vertical pressure, flat pressure, side pressure, peel strength, etc., more fixtures.

6, leather tensile testing machine: leather needs to test tensile strength, tear strength, etc., the test item is relatively simple.

Four, according to the test materials: metal material fixture and non-metal material fixture; according to the test temperature: normal temperature fixture, high temperature fixture, low temperature fixture, high and low temperature fixture;according to use: stretching fixture, compression fixture, bending fixture, cutting fixture, stripping fixture, tearing fixture, sealing fixture, bending and bending fixture;according to the degree of automation: manual fixture, pneumatic fixture, electric fixture, hydraulic fixture.
Can Be Equipped With Multiple Sensors Wire Tensile Testing Machine OEM 0


Customer Support Services:

Ø Installation

Ø Training (Training customer employees)

Ø Calibration

Ø Preventative maintenance

Ø Replacement parts

Ø Assistance via phone or internet

Ø On-site diagnosis and repair/online diagnosis and repair

We will produce the machines according to confirmed PO requirements. Offering photoes to show production process.

After finish production, offer photoes to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.

Deliver the products in confirmed shipping time and inform customer.
