Product Details:
|
| Controller: | Programmable LCD Touch Screen | Temperature Range: | -70 Centigrade Degree To +150 |
|---|---|---|---|
| Humidity Range: | 20% ~ 98% | Brand Name: | GSKA |
| Body Materials: | SUS#304 Stainless Steel | Transport Package: | Strong Wood Case For Climatic Chamber |
| Color: | Can Be Customized | Place Of Origin: | Dongguan China |
| High Light: | Temp Humidity Chamber,Walk In Environmental Chamber |
||
Introduction:
Test material heat, cold, dry resistance, humidity resistance.Suitable for electronics, electrical appliances,Communications, instrumentation, vehicles, plastic products, metal, food, chemical,building materials, medical, aerospaceand other products.
Features:
1.Reasonable structural design, rapid cooling rate.
2. Imported refrigeration system, internal with SUS#304 high temperature resistant stainless steel.
3. More than 30% energy saving is achieved.
4. The test specimen can be easily observed via observation window,
5. Easy to Operate, install and maintain.
6.ational Construction and fast cooling rate
7.Frequency conversion control of wind speed.
8.Adopts international brand of imported parts for cooling system to improve operation reliability
9.Touch screen controller, friendly Man-Machine interface and safety device to ensure simple operation and easy maintenance.
10.Standards Implemented and met GB10592-89 Technical requirements for high and low temperature test chamber GB2423.1-1989 Low temperature test GB2423.2-1989 High temperature test mode
Standard:
GB/Bb T2423.2-89 high temperature test method GB2423.1-89 test A: low temperature test method 6
Ab IEC60068-2-1 low temperature test method GJB150.4-1986 test at low temperature
EIA - 364-59 test at low temperature IEC60068-2-38 temperature cycle
IEC60068-2-78 constant temperature IEC60068-2-30 temperature cycle
EIA - 364-31C temp resistance GB/T2423.3 constant heat test method
Specification:
| GSKA-80 | GSKA--150 | GSKA-225 | GSKA--408 | GSKA--800 | GSKA--1000 | |
| Inner size W*H*DCM |
40*50*40 | 50*60*50 | 50*75*60 | 60*85*80 | 100*100*800 | 100*100*100 |
| External size W*H*DCM | 90*143*100 | 100*153*110 | 110*168*110 | 130*178*120 | 150*193*140 | 150*193*160 |
| Temperature range | -70°C~+150°C(180°C) (A:-20°C B:-40°C C:-60°C D:-70°C ) |
|||||
| Humidity range | 20%~98%R.H.(10%-98%R.H/5%~98%R.H) | |||||
| Temp humidity analytic accuracy / uniformity |
±0.1°C;±0.1%R.H./ ±1.0°C;±3.0%R.H.is special optional condition. | |||||
| Temperature humidity control accuracy/fluctuation |
±1.0°C;±2.0%R.H./ ±0.5°C;±2.0%R.H. | |||||
| Heat/cooling time | About 5.0°C/min;about 1.2°C/min (5~20°C/min is a special optional condition) | |||||
| Inner and outer materials | SUS#304 Stainless steel for inner chamber and Carton Advanced cold plate nano paint for outer. | |||||
| Insulation materials | Resistant to high temp ,high density,formate chlorine,ethyl acetum foam insulation materials | |||||
| Cooling system | Air cooling/single segment compressor(-20°C) ,air and water double segment compressor (-40°C~-70°C) |
|||||
| Protection devices | Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch, super humidity over-temperature protection switch, fuse, failure warning system |
|||||
| Parts | Watching window,50mm testing hole,PL internal bulbs,partition plate,dry and wet ball gauze | |||||
| Controller | TEMI" South Korea"TEMI" "OYO" Japan's "OYO" Brand optional | |||||
| Compressor | Original France"Tecumseh"brand | |||||
| Power | 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz | |||||
Advantage:
