Product Details:
|
| Place Of Origin: | Dongguan China | Cooling Rate: | 0.7c~1.0c/Min (Average) |
|---|---|---|---|
| Temp Range: | 70c~+150c | Maxcapacity: | <1000kn |
| Brand Name: | GSKA | Weight: | 100-500kg |
| Transport Package: | Standard Strong Wood Case | Accuracy Grade: | 0.5 |
Environmental Stability Lab Industrial Altitude Simulation Chamber Low Pressure
Description :
High Altitude Simulation Test Chambers are used in different industries like the instruments and meters, electrical products, materials, spare parts, equipment, etc, but mainly in aviation, aerospace, information, electronics and other industries. This machine can be operated at a low pressure, high temperature, low temperature, under the effect of single factor or multiple conditions at the same time. Simulation of high-altitude conditions like might be found in mountainous regions. Test for electric performance parameters of the specimen.
Structure:
Overall structure: the new design is easier to operate and maintain.
Water and electricity system is separated;
External humidifying design;
Three levels of overheat protection, easy access for refrigeration servicing, etc.
Specification :
| Model | GSKA-252 | GSKA-504 | GSKA-1000 | GSKA-2160 | |
| Inner Size (D*W*H)mm | 600*600*700 | 800*700*900 | 1000*1000*1000 | 1200*1400*1200 | |
| Capacity(KW) | 11 | 15 | 16 | 18 | |
| Chamber Volume(L) | 252 | 504 | 1000 | 2160 | |
Specifications |
Temp range | -70ºC~+150ºC | -70ºC~+150ºC | -70ºC~+150ºC | -70ºC~+150ºC |
| Temp fluctuation | ±0.5% | ||||
| Temp deviation | ≥100ºC, ±3.0ºC(at 101kPa, ATM no load) | ||||
| <100ºC, ±2.0ºC(at 101kPa, ATM no load) | |||||
| Cooling rate | 0.7ºC~1.0ºC/min (Average) | ||||
| Pressure range | 101kPa ~1kPa | ||||
| Pressure accuracy | ±2kPa (101kPa ~ 40kPa), ±0.5kPa (4kPa~40pKa ), ±0.1kPa (4kPa~1kPa) | ||||
| Depressurization rate | 101kPa ~1kPa≤30mins (Room temp) | ||||
| Pressure recovery rate | 10kPa/Min(adjustable) | ||||
| Material | External chamber | Cold-rolled steel sheet(Rust proof&Plastic Spray treated)/Stainless Steel plate | |||
| Internal chamber | Stainless steel(SUS304) | ||||
| Pressurized parts | High quality steel plate(Rust proof & Plastic spray treated) | ||||
| Insulation material | High quality glass wool | ||||
| Cooling System |
Compressor | Semi-Hermetic Compressor | |||
| Cooling way | Water cooled | ||||
| Temp regulating method | Balanced Temperature & Humidity Control System (BTHC) | ||||
| Pump | Rotary vane type vacuum pump | ||||
| Heater | Iron-chrome wire heater | ||||
| Sight window | Circular viewing glass incorporating heat generator | ||||
| Temp Sensor | Pt-100 | ||||
| Controller | Touch Screen Controller | ||||
| Safety Devices | Over pressure, heat and current protection compressor, over temp. protection, over load protection for blower, hydraulic and water lack Protection, leakage protection, phase-lack protection, Pump failure alarm | ||||
| Standard Accessory | Viewing window, Cable Port( 1 located on the left side), Baffle, Baffle frame*2 | ||||
| Power | AC380V/50Hz, 3Phase 4 wires+ Ground Wire. | ||||
| Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations are available | |||||
