Product Details:
|
| Place Of Origin: | Dongguan China | Control: | Computer Control |
|---|---|---|---|
| Drop Height: | 0~1500mm | Weight: | 1000-2000Kg |
| LBrand Name: | GSKA | Impact Capacity: | 20gf, 30gf, 50gf, 100gf (or Specified) |
| Max. Specimen Size: | 1300×1300×1300mm | Load Way: | Electronic Load |
Low Pressure Feed Pipe Pendulum Impact Testing MachineAir Clamper
characteristic:
This series of testing machine is pendulum type host structure, by measuring the difference between the potential energy before the impact of the pendulum and the residual potential energy after the impact to calculate the absorption of the impact sample; The sample bearing is simply supported beam type; The frame and fuselage are cast and processed parts, with good overall rigidity, stability and no deformation; The main engine is equipped with safety protection pin, and is equipped with safety protection net; The impact knife is installed and fixed with screws, easy to replace; Testing machine for semi-automatic control, pendulum, hanging pendulum, impact, put the pendulum are electrical control, and can use the remaining energy after the thrust specimen automatic pendulum ready for the next test, especially suitable for continuous impact test of the laboratory and a large number of impact test of metallurgy, machinery manufacturing, measurement and detection departments. There are dial display, digital display, computer screen display and other models for selection.
| Model | GSKA-220A |
| Drop Height | 300~1500mm Adjustable |
| Machine Dimensions | About 1700*1200*2315mm (L*W*H) |
| Display | LED digital screen |
| Max. Specimen Weight | 80KG |
| Thickness of Ground Plate | 10mm (Solid iron plate) |
| Size of Ground Plate | 1700*1200mm |
| Max Size of Specimen | 800*800*1000mm |
| Size of Arm supporter | 160*250*10mm |
| Deviation of Drop Height | ±10mm |
| Test Method | Face, edge and angle drop test |
| Transmission | Electronic |
| Horizontal Deviation of Impact Plate | ≤1° |
| The Deviation of Horizontal Angle in Falling | ≤1° |
| Voltage | AC 380V, 50Hz |
| Power | 1.85KWA |
| Net Wight | 300KG |
| **Design Criteria : ISTA-1A ISO 2248, JIS Z0202-87, GB/T4857.5-92 | |
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
FAQ:
1. How about your warranty?
Generally,our warranty is two years. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers may go to your place for better service.
2. How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
3. What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging - balance payment - packing - delivery - customer receiving - after service.
4. How to install and use the product?
The product is shipped with an operating instructions and video of English version.
