Product Details:
|
| Warranty: | 1 Year | Place Of Origin: | Guangdong, China |
|---|---|---|---|
| Model: | GSA-941V | Power Source: | AC220V |
| Control: | Computer Control | Maxcapacity: | <1000KN |
| Maximum Test Load: | 200kg | Amplitude Of Vibration: | 1" (25.4mm) ±1.5% |
| Highlight: | 200kg Vibration Test Equipment,1000KN Vibration Test Equipment,Synchronous Vibration Testing Machine |
||
Maximum Test Load 200kg Vibration Test Equipment For Vehicle Simulation Transport
product presentation:
Electromagnetic vibration testing machine for transportation is for a variety of packaging materials, PC boards, electrical products as well as the simulated transport vibration test of the packaged products, to assess the degree of vibration-resistance.... simulate the transport process Caused damage because of the vibration force, the test results can be used as the reference of the design packaging.
Features:
1. Digital instrument displays vibration frequency.
2. Synchronous quiet belt drive, very low noise.
3. Test clamping rail type, easy to operate, safe.
4. Machine base with heavy channel steel damping pad, easy installation, smooth operation, no need to install the ground screws.
5. DC motor speed regulation, smooth operation, strong load capacity.
6. Rotary vibration ( commonly known as running horse ), in line with European and American transport standards.
Product parameters of Vibration testing machine :
| Model | GSA-941V |
| Vibration direction | Rotary (runner) |
| Maximum test load | 200KG |
| Vibration frequency (rev/min) | 100 to 300RPM continuously adjustable |
| Amplitude of vibration | 1" (25.4mm) ±1.5% |
| Counters | 0~999.99 hours |
| Worktop dimensions LxW(cm) | 200×200 |
| Table dimensions LxWxH(cm) | About 200×200×65 |
| Weight | 180kg |
| Power supply | 1∮,AC220V,10A |
| Digital speed accuracy | No greater than ±3 rpm |
| Operating time setting range | 0~99H99/0~99M99/0~99S99 |
| Shaker material | Stainless steel |
| Clamps | Aluminium |
FQA:
Q: What about the transportation?
A: We can delivery by air to your airport, or by sea to your seaport, and we can also delivery to your company by express.
Q: What about the Voltage?
A: We can change the voltage as your requirement, you can confirm the voltage to us before delivery.
Q: What about the after-sale service?
A: Guarantee period is 12 months, after the warranty, we also provide life-long paid repair or service. Response within 24 hours for any problems.
Overseas training, installation is available.
Q: What about the delivery date?
A: The test machine most are in stock,can delivery within 15-30 working days after received the payment.We can also accept the urgent order for
prompt shipment.
Q: What is the payment term?
A: Payment by T/T, L/C ,Western Union
