Product Details:
|
| Outer Chamber Material: | SUS 201 Double Layer Stainless Steel Plate | Exterior Chamber Material: | Stainless Steel Plate + Powder Coated |
|---|---|---|---|
| Power: | 220V , 50Hz | Controller Resolution: | ±0.3℃；±2.5%RH |
| Xenon Lamp Power: | 2.5kw | Temperature Uniformity: | ±2.0℃ |
| Condenser: | Water-cooled Condensing Agent | Customized Support: Customized Support: | OEM |
| High Light: | Environment Test Equipment,Environment Chamber |
||
220V 50Hz High And Low Temperature Cycle Test Chamber Climate Touch Screen
Product Application:
Automobile industry, communication industry, construction industry, aerospace, naval ships and ships, electronics industry, clothing industry, luggage industry, furniture industry, etc
Refrigeration system:
(1) Refrigeration system and compressor
1. Refrigeration compressor: the original imported French "Taikang" fully enclosed refrigeration unit.
2. Cooling method: air cooling
3. Refrigerant: environmental protection refrigerant
4. Main refrigeration accessories: Japan "Arugong" solenoid valve; American "Emerson" drying filters, etc.
Excellent quality of domestic and foreign well-known brands of air-cooled condenser and fin multi - section evaporator.
(2) Advantages of refrigeration system
1. Improved lubrication performance and lower piston temperature bring greater reliability;
2. Streamline body to improve airflow management; Reduced pressure, improved refrigeration efficiency;
3. Top unloading valve provides continuous minimum discharge line pulse;
4. SENTRONIC provides reliable lubrication protection system;
5. Use of environmentally friendly refrigerants R23, R404A (excluding CFCS) which are not prohibited by the Montreal convention or the amendment to London.
| Specification | |||||||
| Model | GSKA-050 | GSKA-080 | GSKA-108 | GSKA-216 | GSKA-252 | ||
| Test Area Dim. W× H× D(mm) | 360× 350× 400 | 500× 400× 400 | 600× 400× 450 | 600× 600× 600 | 600× 700× 600 | ||
| External Dim. W× H× D(mm) | 1200× 1820× 1500 | 1430× 1950× 1600 | 1510× 1850× 1850 | 1510× 2050× 2000 | 1510× 2150× 2000 | ||
| High Temp. Range | +80º C---+200º C | ||||||
| Low Temp. Range | -10º C -- -40º C; -10º C ---60º C; -10--- -70º C | ||||||
| Test Temp. Range | +60º C-- +150º C; | ||||||
| -10º C--- -40º C; -10º C---55º C; -10º C--- -65º C | |||||||
| Ferformance | Temp. Constancy | ± 1º C | |||||
| Temp. Recover Time | 3 -- 5min | ||||||
| Heat-at Time | º C | 150 | 150 | 150 | 150 | 150 | |
| min | 30 | 40 | 40 | 40 | 40 | ||
| Pull-downTime | º C | -40 -50 -65 | -40 -50 -65 | -40 -50 -65 | -40 -50 -65 | -40 -50 -65 | |
| min | 60 70 80 | 60 70 80 | 80 90 100 | 90 100 110 | 100 110 120 | ||
| Material | Exterior | Stainless steel piate+Powder Coated | |||||
| Interior | SUS#304 stainless steel piate | ||||||
| Insulation | PU & Fiberglass wool | ||||||
| Systems | Cirulation | siroco fan | |||||
| Heating | Chrome steel strip wire heater | ||||||
| Cooling | Compressor+evaporator fins+air-cooling(or water-cooling)condenser | ||||||
| Controller | CLCD-9800 | ||||||
| Other Components | Control status indicator lights, experiment separation shelves(freely adjustable 2pcs) | ||||||
| Sevey Devices | Overheating prevention circuit-breaker, compressor overload protection, control system overload prevention, breakdown idicator lihgt, high-low compressure protection swith. | ||||||
| Power Source[K. W. ] | AC 3Ψ 380V 60/50Hz | ||||||
| Customization | Customization of inner chamber size, temperature range, etc. | ||||||
We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency
- A variety of industrial and laboratory drying ovens;
- Muffle and chamber furnaces;
