Product Details:
|
| Warranty: | 1 Year | Instrument Control Precision: | ±0.1°C 2%RH |
|---|---|---|---|
| Power: | Electronic | Humidity Range: | 20%~98%RH |
| Temperature Range: | -20~150°C | Studio Size(mm): | 500*400*500 |
| Studio Size: | 100L | Color: | Gray And White |
| High Light: | Environment Test Equipment,Environment Chamber |
||
High-Precision Energy-Saving Walk-In Environmental Test chamber
The test chamber is used to simulate the vibration of the plane. The temperature range is -55°℃ ~ +75°℃ and the cycling rate is 15°C/ min.The chamber adopts compressor to cool which temperature stability and the economic efficiency are greatly improved compared with traditional cooling nunit liquid nitrogen.
Features:
1.This series product use polyurethane panel,the inner surface is made of stainless steel,the surface of the shell is made of color steel.It has firm structure and easy installing,with a elegant appearance and novel design.
2.We adopt import fittings as our main control fittings to ensure oven quality.
3.Use the newest cooling conrol model in the international , it can adjusted the cooling power of the compressor reach to 0%-100% automatically to realize low energy consumption run of the machine.
4.Configured with Multi-panel sliding doors and inboard type Illumination,, it provides good observation for the specimen's working.
5.Size and performance can be customized by customers.
This system has simple operation and convenient to install,training and Maintenan.
| Temperature Range | A:0~90℃ B:-20~90℃ C:-40~90℃ D: -70~90℃ |
| Humidity Range | 20%RH-98%RH Low humidity : Maximum 5%R.H. |
| Temperature Fluctuation | ≤±0.5℃ |
| Temperature Deviation | ≤±2℃ |
| Temperature Uniformity | ≤±2℃ |
| Humidity Fluctuation | ≤±2.5% |
| Humidity Deviation | ≤+2/-3%R.H. (when humidity >75%RH), ≤±5RH% (when humidity <75%RH) |
| Heating Rate | Approx 1~ 3℃/mins,average non-linear ,no load |
| Cooling Rate | Approx 0.5~ 1℃/ mins,average non-linear ,no load |
| Temperature Overshoot | ≤±2℃ |
| Internal Material | 1.0mm thick SUS#304 high &low temperature resistance stainless steel. |
| External Material | 1.2mm thickness High temperature spray powder coated galvanized plate |
| Compressor | Tecumseh (France)-fully air-cooled double-fall cooling compressor. Or Bock (Germany) semi-enclosed air-cooled refrigeration. |
| Options | Dry air purge system ,Humidifying water auto purifying and supply system, New air ventilation system ,Fire-proof, explosion-proof & alarm system ,Low temperature low humidity, low temperature high humidity test requirement, Remote computer, mobile alarm function |
