Product Details:
|
Accuracy: | Temperature ±0.1℃, Humidity ±1%RH | Temperature Fluctuation: | ±1.0℃ |
---|---|---|---|
Power: | 220V , 50Hz | Controller Resolution: | ±0.3℃;±2.5%RH |
Impact Recovery Time: | (-40)℃~(+150)℃≤5min | Temperature Uniformity: | ±2.0℃ |
Condenser: | Water-cooled Condensing Agent | Keyword: | Climatic Test Chamber |
High Light: | Environmental Humidity Chamber,Humidity Test Chamber |
The main function of an environmental chamber is to test the behaviour of the products we use every day, in extreme climatic conditions. The following applications are examples of how a climatic chamber may be used…
1. Testing of the influence of temperature and humidity on the properties of textiles, building materials, plastics, composites, adhesives, metals, electronic components, etc.
2. Storage of building material test specimens
3. Incubation of fungal spores on plants under humidity
Features:
1, The inner chamber is made of mirror stainless steel.
2, Semicircular corners inner chamber is easy to clean.
3, Shelf can be adjusted.
4, LED microcomputer controller make the temperature and humidity constant.
5, Touch key parameter setting.
6, Timer, over temperature alarm function.
7, Large angle observation window, easy to watch the goods in the inner chamber with lighting.
8, Large-capacity humidifier, easy to use
Detailed Parameters:
Inside size WxHxD (cm) | 40x50x40 | 50x60x50 | 50x75x60 | 60x85x80 | 80x95x80 | 100x100x80 | 100x100x100 |
Outside size WxHxD (cm) | 100x170x87 | 105x175x97 | 115x190x97 | 135x195x115 | 145x185x137 | 145x210x130 | 147x210x140 |
Temperature range | -70℃~+100℃(150℃) (A:+25℃ B:0℃ C:-20℃ D:-40℃ E:-50℃ F:-60℃ G:-70℃) |
||||||
Humidity range | 20%~98%R.H.(10%-98%R.H/5%~98%R.H is the specific condition) | ||||||
Accuracy/ uniformly | ±0.1℃;±0.1%R.H./ ±1.0℃;±3.0%R.H. | ||||||
Accuracy / volatility | ±1.0℃;±2.0%R.H./ ±0.5℃;±2.0%R.H. | ||||||
Heating / cooling time | About 4.0℃/min;about 1.0℃/min(5~10℃/mm is the specific condition) | ||||||
Inside material | Stainless steel SUS 304# | ||||||
Insulation material | High-temperature high-density amino acid ethyl ester foam insulation materials, | ||||||
Cooling system | Air-cooled/ single-stage compressor(-20℃), wind, water cooled/two-stage compressor(-40℃~-70℃) | ||||||
protection | compressor overload switch, high and low pressure protection switch, over-humidity-temperature protection switches, fuses, warning system | ||||||
accessories | recorder(purchase), view window, 50mm testing hole, PL lamp, clapboard, Dry and wet gauze ball | ||||||
controller | TEMI300 digital controller from South Korea | ||||||
compressor | France Tecumceh | ||||||
power | 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz |
Chamber Design Features:
1. High performance and quiet operation (68 dBA)
2. Space-saving designed for flush installation to wall
3. Full thermal break around doorframe
4. One 50mm diameter cable port o left, with flexible silicone plug
5. Accurate wet/dry-bulb humidity measurement system for easy maintain
We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
