Product Details:
|
| Compressor: | French Tecumseh Brand, Germany Brand | Humidity Range: | 50%～98%R.H. |
|---|---|---|---|
| Working Volume: | 5.4 CBM | Applied Standard: | IEC 60068-2-52 And Etc. |
| Keyword: | Environmental Test Chamber | Temperature Range: | 15℃～70℃ |
| Spray Pressure: | 1.00±0.01kgf/cm2 | Spray Volume: | 1 To 2ml/h Adjustable |
| High Light: | Environmental Humidity Chamber,Humidity Test Chamber |
||
Temperature Resolution 0.01℃ Environmental Stress Screening Chamber OEM
Equipment Overview:
This system is composed of conditioning chamber, dry heater, evaporator (refrigeration), humidifier extension pipe, centrifugal fan, etc. The purpose is to adjust the dry temperature and humid air in the conditioning chamber after sufficient mixing, and sent into the working chamber, enter into the return air vent, sent back to the adjustment cavity to continue the cycle, repeating the cycle.
Adopting the air-flow spray method and the principle of siphon, the absorbed salt solution is atomized through the nozzle, and the atomization particle size is uniform, which can ensure the continuity and stability of the test.
Complied Standards & Clauses:
This walk-in comprehensive salt spray test chamber can perform neutral salt spray test (NSS), acetic acid salt spray test (ASS), copper accelerated acetic acid salt spray test (CASS) according to GB/T10125－2012, ASTM B117-2002, BS7479:1991, cyclic corrosion test can also be carried out according to IEC 60068-2-52 kb test, GM9540P, PV1210 and other standards.
This test chamber meets the requirements of ES 5454, GJB150A, ASTM B117, ASTM B368, ASTM B380, ASTM D1735, ASTM D2247, ASTM G85 A1, GM4465P, ISO9227, DIN 50021, PV1210, NES M0007, 33 (CCT-1 method),etc.
Technical Parameters:
| 1. Inner chamber capacity |
5.4 cubic meters Can be customized |
| 2. Inner chamber size |
1500*1500*2400mm (W*D*H) Can be customized |
| 3. Outer dimensions |
1800*2000*3000mm (W*D*H) Subjected to actual design |
| 4. Temperature range | 15℃～70℃ (Adjustable) |
| 5. Temperature accuracy | Temperature resolution: 0.01℃ |
| Temperature uniformity: ≤2℃ | |
| Temperature fluctuation: ±0.5℃ | |
| 6. Heating and cooling rate |
Heating up: 15℃～+60℃≤50min, Cooling down: +60℃～15℃≤70min, |
| 7. Humidity range | 50%～98%R.H. |
| 8. Humidity deviation |
±3%R.H(>75%R.H) ±5%R.H(≤75%R.H) |
| 9. Spray volume | 1.0～2.0 mL/80cm2/H (collect at least 16 hours, take the average value) |
| 10. Spray pressure | 1.00±0.01kgf/cm2 |
| 11. PH value of potion | Neutral 6.0～7.0; Acidic 3.0～3.1 |
| 12. Spray solution | PH value: Neutral 6.5～7.2; Acidic 3.1～3.3 |
| 13. Time range | 1S ～ 9999H, the time can be set arbitrarily |
| 14. Neutral salt water spray test temperature | Test room: 35℃±1℃, saturated air barrel: 47℃±1℃ |
| 15. Drying test temperature | Laboratory temperature: 50~70℃±2℃, humidity: less than 30%±3%RH |
| 16. Wetting test | Laboratory temperature: 40~50℃±2℃, humidity: more than 93%RH, adjustable |
| 17. Room temperature maintenance | Keep the laboratory temperature at 25℃±1℃ |
| 18. Inner chamber material | 10MM thick PP plastic board |
| 19. Outer chamber material | 10MM thick PP plastic board |
| 20. Door opening size | The gate is set in the depth direction and adopts a single door structure, size: 1100×1500mm (W*H, the size can be adjusted) |
| 21. Observation window | There is an observation window (size: 300×400 mm (W*H), which can be adjusted) on the door, it is the hollow resistive film heating and anti-frost observation window |
| 22. Product weight | Approx. 1000 Kg |
| 23. Product power supply | Three-phase five-wire, 20KW |
| 24. The internal design of the salt spray chamber |
The top design and the condensate on the inner wall will not drip on the test sample (slope structure is adopted)
|
Advantage:
1 Programmable control, touch screen operation
2. It can spray regularly, intermittently and evenly
3.24 hours online
4.Sample chamber of each model
5. Best price, fast delivery
6.OEM,ODM
7.Oversea offices
8.Own import and export business license
9.ISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
Welcome to inquiry about Walk In Salt Spray Corrosion Environmental Test Chamber ,thank you
