Product Details:
|
Materials: | SUS#304 Stainless Steel Plate | Temperature Fluctuation: | ±1.0℃ |
---|---|---|---|
Customized Support: | OEM | Condenser: | Water-cooled Condensing Agent |
Cooling Rate/min: | 1 Degree | Temperature Uniformity: | ±2.0℃ |
Power: | 220V , 50Hz | Keyword: | Environmental Chambers |
80L- 1000L Reliable Climatic Environmental Temperature Humidity Drug Stability Test Chamber
Optional Accessories of test chamber:
1. Low humi. Dehumidifying system
2. Inner glass door with manual operating ports
3. Temp./ humi. Recorder
4. Pure water treatment device
5. Reverse osmosis water purifier
6. RS-485 interface can be linked to PC and achieve multi-level control and recording software management.
7. LN2 / LCO2 fast cooling-down system
1. The box body is processed and formed by CNC machine tools, with beautiful appearance and non-reaction handle, which is easy to operate.
2. The inner tank of the box is made of imported high-grade stainless steel (SUS304) mirror panel, and the outer tank of the box is sprayed with A3 steel plate, which increases the appearance texture and cleanliness.
3. The water replenishment tank is placed in the lower right part of the control box, and has automatic water shortage protection, which is more convenient for the operator to replenish the water source.
4. The large observation window is equipped with lights to keep the inside of the box bright, and the tempered glass embedded in the heating body is used to clearly observe the situation in the box at any time.
5. The humidification system pipeline is separated from the control circuit board, which can avoid failure due to water leakage in the humidification pipeline and improve safety.
Inner chamber size
w×h×d(cm)
|
40×50× 40 |
50×60× 50 |
50×75× 60 |
60×85× 80 |
100×100× 80 |
100×100× 100 |
||
Exterior chamber size
w×h×d(cm)
|
90×140 ×95 |
100×150 ×105 |
100×165 ×115 |
110×175 ×135 |
150×190 ×135 |
150×190 ×155 |
||
Testing temperature range | -73℃ ,-60℃,-40℃,-20℃,0℃~150℃,180℃ | |||||||
Testing humidity range | 20%RH~98%RH(10%RH~98%RH Or 5%RH~98%RH) | |||||||
Performance | Temp.humi.fluctuation | ±0.2℃,±0.5%RH | ||||||
Temp.humi.uniformity | ±1.5℃;±2.5%RH(RH≤75%),±4%(RH>75%)empty load,after stabilization | |||||||
Temp.humi.resolution | 0.01℃;0.1%RH | |||||||
Heating-up time | ℃ | 10 0 15 0 | ||||||
min | 30 40 | 30 40 | 30 45 | 30 45 | 30 45 | 30 45 | ||
Cooling-drow time | ℃ | 0 -20 -40 -60 -70 | ||||||
min | 25 40 50 70 80 | |||||||
Material | Exterior chamber material | Stainless steel+Powder coating | ||||||
Interior chamber material | SUS#304 Stainless steel | |||||||
Insulation material | PU fiberglass wool | |||||||
System | Air circulation system | Cooling fan | ||||||
Heating system | SUS#Stainless steel high-speed heater | |||||||
Humidification system | Surface evaporation system | |||||||
Refrigeration system | Imported tecumseh compressor+
fin type evaporator+air(water)cooling system
|
|||||||
Dehumidifying system | ADP critical dew point cooling/dehumidifying method | |||||||
Controlling system | Digital electronic indicator+SSR+PID | |||||||
Other components | Multi-layer vacuum glass observation window, cable port(50mm),
controlling status indicator lamp, chamber light, specimenloading
shelf(2pcs, position adjustable) |
|||||||
Safety protection device | Over-heat protection circuit breaker, compressor overload protection,
control system overload protection, humidifying system overload
protection indicator lamp |
|||||||
Power supply | AC 1 phase 220V; 3 phase 380V 60/50Hz | |||||||
Customization service | Non-standard or special requirements are all welcome |
We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency
Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
