Product Details:
|
| Pressure Range: | Normal Pressure 0.5kpa 500pa) | Temp Fluctuation: | ±0.5% |
|---|---|---|---|
| Internal Chamber: | Stainless Steel(SUS304) | Test Time: | 1~9999 Minutes(arbitrary Setting) |
| Keyword: | Altitude Test Chamber | Cooling Rate: | 0.7c~1.0c/Min (Average) |
| Brand: | GSKA | Power: | Electronic, Electronic |
OEM Temperature Humidity Test Chamber Atmospheric Pressure～0.5kpa
Wide Range of Climatic Chambers:
·Temperature (Humidity) Test Chambers
· Weather Aging Chambers (Ozone, Xenon, UV, etc)
· IP Level Test Chambers (Dust, Rainfall, etc)
· Salt Spray Chambers
· Walk-in Climatic Chambers
Characteristics:
1. Environment Test High Low Temperature Humidity Pressure Altitude Test Chamber Main box structure internal pressure structure
2. Environment Test High Low Temperature Humidity Pressure Altitude Test Chamber Control system of temperature and humidity: fan, heater, evaporator,h umidifier
3. Refrigeration mode: mechanical compression binary refrigeration system
4. Vacuum units: rotary vane vacuum pump
5. Control panel: temperature, humidity and pressure controlled display screen, over temperature protection device, light switch.
Application Field:
Environment Test High Low Temperature Humidity Pressure Altitude Test Chamber ,Electrical,electronic,military industry and household products.According to GB,GJB and IEC standard,to do Low pressure test chamber high low temperature,humidity thermal,low pressure and other environmental and reliability test. General introduction: This equipment is composed of test room formed by pressure-containing box shell and insulation structure, refrigeration system, add wet system,vacuum system and electric control system and other components. precision instruments, and to a great extent electronics parts in general.
| Pressuren Range | Atmospheric pressure～0.5kpa | ||
| Temperature Uniformity | ≤2℃ | ||
| Temperature Fluctuation | ±0.5℃ | ||
| Ramp up Rate | -25℃～100℃≤50min | ||
| Ramp Down Rate | 25℃～-20℃≤60min | ||
| Depressurization Time | (Atmospheric pressure～0.5kpa)≤45min | ||
| Inner material | Mirror Stainless Steel-SUS#304 | ||
| Exterior Material | A3 Steel board with powder coated | ||
| Observing Window | 1 PC(215×275mm)/(395*395mm); | ||
| Sensor | PT-100Ω Dry &Wet Bulb | ||
| Insulation way of Chamber | Glass fiber cotton or polyurethane foam | ||
| Heater | Nickel-chromium naked wire heating | ||
We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
