Product Details:
|
| Temperature Range: | -160℃ ~ +1000℃ | Temp Fluctuation: | ±0.5% |
|---|---|---|---|
| Internal Chamber: | Stainless Steel(SUS304) | Test Time: | 1~9999 Minutes(arbitrary Setting) |
| Keyword: | Altitude Test Chamber | Cooling Rate: | 0.7c~1.0c/Min (Average) |
| Brand: | GSKA | Power: | Electronic, Electronic |
CE Constant Temperature And Humidity Test Chamber Touch Display Screen
Product features:
1. Arc shape and fog surface line processing, high texture appearance, and the plane without reaction handle, easy to operate, safe and reliable;
2. Closed structure, using powerful circulating motor, low voice freezing device; With shockproof pad, so that the machine can keep quiet and stable in the process of operation;
3. It has the power test function of the test piece (load test);
4. Philips lighting window lamp, built-in high temperature resistant defogging device, easy to observe the test of products in the box; With a variety of protective devices, safe and reliable performance.
5. Ultra-thick insulation layer, five layers of vacuum glass in observation window, the cooling capacity and heat are not lost, ensuring rapid and stable cooling.
6. The ventilation and humidity meter should be integrated with the whole machine. It cannot be attached by the user at will. This is because the ventilation and humidity meter has strict requirements on wind speed, which is different from that of the temperature and humidity test box.
7. The surface escape method is used for humidification. Water molecules are added into the air in this way. The humidification surface is large, the release is stable, the humidity fluctuation is small and the distribution is uniform. If the use of ultrasonic or steam humidification, the addition of small water droplets, that is, the addition of moisture rather than the real humidity, humidification surface is small, large impact, humidity fluctuation and uneven distribution.
8. The suspended items under test will not swing without extra fixing. Once they swing, they will have difficulty reading and collision with each other.
9. The objects under test will not block each other. In the case of blocking, the equipment can only meet the target in the empty box test, but the uniformity index is very poor in the actual use.
10. The cooling parts of the equipment can not be condensed or frozen. The longer the time, the more ice will be frozen. Finally, all of them will be blocked, and the air can not pass through.
| Pressuren Range | Atmospheric pressure～0.5kpa | ||
| Temperature Uniformity | ≤2℃ | ||
| Temperature Fluctuation | ±0.5℃ | ||
| Ramp up Rate | -25℃～100℃≤50min | ||
| Ramp Down Rate | 25℃～-20℃≤60min | ||
| Depressurization Time | (Atmospheric pressure～0.5kpa)≤45min | ||
|
Inner material
|
Mirror Stainless Steel-SUS#304 | ||
| Exterior Material | A3 Steel board with powder coated | ||
| Observing Window | 1 PC(215×275mm)/(395*395mm); | ||
| Sensor | PT-100Ω Dry &Wet Bulb | ||
| Insulation way of Chamber | Glass fiber cotton or polyurethane foam | ||
| Heater | Nickel-chromium naked wire heating | ||
We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
