Product Details:
|
| Normal Wire Diameter: | 50um | Temperature Fluctuation: | ±1.0℃ |
|---|---|---|---|
| Customized Support: | OEM | Condenser: | Water-cooled Condensing Agent |
| Box Material: | SUS 304 Stainless Steel | Temperature Uniformity: | ±2.0℃ |
| Power: | 220V , 50Hz | Keyword: | Environmental Chambers |
Rain Spray Environmental Test Chamber Dustproof Stainless Steel
Rain spray test chamber simulates the watet drip environment to test the water resistance and sealing of the samples during storage, transportation and usage. It is widely applied to electrical and electronic products, lamps and lanterns, electrical cabinet, electrical components, automobile, motorcycle and its spare parts and other products. It provides the basis to improve the performance of the products.
This product uses the scientific design makes the device capable of realistic simulation drip, water spray, splashing water, environmental, water and so on. Into the overall control system and the use of inverter technology, making the rotation angle of rainfall in the test frame, spray angle and swing the pendulum swinging spray volume can automatically adjust the frequency.
Test Area & Shelf:
●Interior of Chamber is SUS304 stainless steel.
●A stainless steel shelf for placing test specimens
●Standard load of shelf is 50kg
●Normal wire diameter is 50 um.
●Normal width of a gap between wires is 75um.
●Built-in power interface for test specimen
●Test chamber internal illumination
●Vacuum system for specimen
Performance parameters:
| Internal dimensions (mm) | 800*1000*1000 | 1000*1000*1000 | 1000*1500*1000 | 1000*2000*1000 |
| Overall dimensions (mm) | 1040*1450*1960 | 1200*1450*1960 | 1250*1900*1960 | 1300*2400*1960 |
| Temperature range | Ambient to +50℃ | |||
| Relative Humidity | <30%RH | |||
| Normal wire diameter | 50um | |||
| Normal width of a gap between wire | 75um | |||
| The Talcum powder amount | 2kg ~ 4kg/m3 | |||
| Fight time | 0 ~ 99H59M | |||
| Fan cycle time | 0 ~ 99H59M | |||
| Specimen power outlet | Dust-proof socket AC220V 16A | |||
| Controller | programmable color display touch screen controller | |||
| PC Link, R-232 interface | ||||
| Vacuum system | Equipped with a pressure gauge, air filter, pressure regulator, connecting tube | |||
| Exterior material | Steel Plate with protective coating | |||
| Interior material | SUS304 stainless steel | |||
| Safety System | Electric leakage, short circuit, Over-temperature, motor overheating Over-current protection/ Power failure memory function for controller |
|||
| Power supply | 380V 50HZ | |||
| Standard | IEC60529, ISO20653 | |||
Middle service:
--Give you best offer.
--Provide discount for many sets order.
--Do customer's request.
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
After sale service:
--14 months warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts.
--Remote control technical consult.
--Free installation DVD.
--Maintenance plan.
