Product Details:
|
| Impact Capacity: | 20gf, 30gf, 50gf, 100gf (or Specified) | Machine Weight: | 75kg |
|---|---|---|---|
| Brand: | GSKA | Application: | Packaging |
| Impact Height: | 300~1000mm | Power: | Electronic |
| Place Of Origin: | Dongguan China | Certification: | CE SGS ROHS UL CE |
| High Light: | 300mm Mechanical Shock Tester,1000mm Mechanical Shock Tester |
||
Superior Quality Mechanical Shock Tester With 300-1000mm Impact Height
Introduction to the:
Drop testing machine for the product packaging in the simulation of different edges, angles, surface at different heights when falling to the ground, so as to understand the product damage and evaluate the product packaging components in the fall can withstand the fall height and impact strength. According to the actual situation of the product and national standards within the scope of improvement, perfect packaging design.
Reference standard: GB/T 2423.8-1995 Environmental testing of electrical and electronic products -- Part 2: Test methods -- Test Ed: free drop
The characteristics of:
The machine can make free drop test on the surface, Angle and edge of the package. It is equipped with digital height display instrument and adopts decoding device to track the height, so as to accurately give the product's drop height, and the error with the preset drop height is not more than 2% or 10mm. This machine adopts single arm double column structure, with electric reset, electric drop and electric lifting device: easy to use; Unique hydraulic buffer device greatly improves the service life, stability and safety of the machine single arm setting, can be conveniently placed products, drop Angle impact surface and floor plane Angle error is less than or equal to 5.
Proper use method:
1. Specimen can be free to choose surface, edge, Angle three state drop test
2. Drop height can be preset, when the specimen rose to preset height automatically positioning
3. The release mechanism is free, flexible and reliable to ensure that the specimen is not affected by any external force at the moment of
release and on the way of free fall, so as to ensure the required drop state of the specimen.
4. Scientific and reasonable structure, safe and reliable use, slope impact test bench
5. Transport packaging for oblique platform impact test
| Model | GSKA-220A |
| Drop Height | 300~1500mm Adjustable |
| Machine Dimensions | About 1700*1200*2315mm (L*W*H) |
| Display | LED digital screen |
| Max. Specimen Weight | 80KG |
| Thickness of Ground Plate | 10mm (Solid iron plate) |
| Size of Ground Plate | 1700*1200mm |
| Max Size of Specimen | 800*800*1000mm |
| Size of Arm supporter | 160*250*10mm |
| Deviation of Drop Height | ±10mm |
| Test Method | Face, edge and angle drop test |
| Transmission | Electronic |
| Horizontal Deviation of Impact Plate | ≤1° |
| The Deviation of Horizontal Angle in Falling | ≤1° |
| Voltage | AC 380V, 50Hz |
| Power | 1.85KWA |
| Net Wight | 300KG |
| **Design Criteria : ISTA-1A ISO 2248, JIS Z0202-87, GB/T4857.5-92 | |
FAQ:
1. How about your warranty?
Generally,our warranty is two years. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers may go to your place for better service.
2. How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
3. What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging - balance payment - packing - delivery - customer receiving - after service.
4. How to install and use the product?
The product is shipped with an operating instructions and video of English version.
