Two-Dimensional Measurement Vision System High Precision Measurement

Two-Dimensional Measurement Vision System High Precision Measurement
Two-Dimensional Measurement Vision System High Precision Measurement Two-Dimensional Measurement Vision System High Precision Measurement Two-Dimensional Measurement Vision System High Precision Measurement

Large Image :  Two-Dimensional Measurement Vision System High Precision Measurement

Product Details:
Place of Origin: Donggaun,china
Brand Name: GSKA
Certification: CE SGS ROHS UL
Model Number: GSA-52F
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiate
Packaging Details: Export package
Delivery Time: 15-30working days after received deposit
Payment Terms: L/C, T/T
Supply Ability: 160 Set / Sets per Month

Two-Dimensional Measurement Vision System High Precision Measurement

Description
Warranty: 1 Year Z-Axis Travel: 75mm
Accuracy (Wide-Field With Binding): 3+L/150um Accuracy(High-Precision With Binding): 2+L/150um
Repeatability(High-Precision): 1.5um Max. Load Capacity: 5kg
Accuracy (Wide-Field Without Binding): 3um X/Y-Axis Travel: 200X200mm
High Light:

Vision Measurement System

,

Optical Vision System

Two-Dimensional Measurement Vision System High Precision Measurement



Product Characteristic:


Benchtop Instant Measurement System
Table structure, compact size, easy to handle.
One-Button Measurement,can also be matched with IO signal to achieve automatic measurement.
The report can be uploaded automatically into data management system.
High Precision Measurement Under Surface Light
Equipped with Double Magnification Telecentric Lens and two 20MP camera, auto multi-angle surface light and optional coaxial surface light.
With the independent powerful AI edge calculation algorithm, it can easily realize precise edge searching on the surface and filter invalid areas for boundary clutter.
The measurement repeatability of surface light can also reach the similar level as that of bottom light.
Fast Measurement And Easy Operation
Can measure 100 dimensions in one second, greatly reducing the measurement time.
The operation interface of the software is simple and easy to be understood, and the measurement program and parameter setting can be easily written.
With automatic focusing, automatic positioning and automatic measurement function, anyone operation can obtain stable measurement results.



Technical Specifications:



Model GSA-52F GSA-53F GSA-54F
Measuring Range X φ100 200mm 300mm
Y 200mm 200mm
Z 75mm 75mm 75mm
FOV High-Precision Mode 26mm X 18mm
Wide-Field Mode φ100mm
Repeatability High-Precision Mode ± 1.5μm
Wide-Field Mode ± 3μm
Minimum Unit 0.1μm
Accuracy High-Precision Without Binding ±1.5μm
With Binding   ±2+L/150μm ±2+L/150μm
Wide-Field Without Binding ±3μm
With Binding   ±3+L/150μm ±3+L/150μm
Weight 33 Kg 45 Kg 50 Kg
Optical System Camera 1" 20MP BW Camera * 2
Lens Double Magnification Telecentric Lens
Surface Light Two-Ring Liftable Light
Bottom Light Green Parallel Bottom Light
Capacity 5 Kg
Measuring Software GD&T Software
Power Supply 220V±10%,50Hz
Working Environment Temperature: 20±3ºC, Humidity: 30-80%, Vibration: <0.002g,15HZ
Dimension (L*W*H) mm 600*300*650mm 600*410*650mm 600*510*650mm
