Product Details:
|
| Warranty: | 1 Year | Place Of Origin: | Donggaun,china |
|---|---|---|---|
| Power: | Electronic | Material: | Granite,steel |
| Measuring Range: | 200*100*150mm | Accuracy: | 3um |
| Resolution: | 0.001mm | Lens Magnification: | 0.7-4.5X |
| High Light: | Vision Measurement System,Optical Vision System |
||
High Precision Measurement Vision System Positioning Accuracy ±0.01mm
product presentation :
The GSA series is a basic manual video measurement system that has been widely used in precision measurement in industries such as machinery, electronics, aerospace, automotive, military, and mold.
1. It can measure points, lines, circles, arcs, ellipses, and rectangles, and has multi-point positioning function to improve accuracy.
2. In terms of metrology, this machine can test size, width, length, height, thickness, diameter, angle, straightness, flatness, perpendicularity, roundness, coaxiality, etc.
3. Measurement combination, center structure and intersection structure, midpoint structure, straight line structure, circle structure and viewpoint structure.
Features
1. It adopts TEO™ 1 / 3'' color CCD camera, the cross-line generator is the measuring aiming system.
2. Digital measurement and data processing system are made up by the two coordinate's studio, the optical grating and the professional video card.
3. It has RS-232 interface with a computer and specialized measurement software which can also processes and output circular mapping. Measurement data can be directly transformed into AutoCAD file and make a full work circle. The data also can be exported in Excel, Word to generate reports for statistical analysis.
Sepcifications
| Model | GSA-X45 | GSA-X46 | GSA-X47 | |
| Worktable | Worktable D(mm) | 500*330 | 606*466 | 706*566 |
| Glass Table Size(mm) | 350*280 | 450*350 | 550*450 | |
| X,Y Stroke(mm) | 300*200 | 400*300 | 500*400 | |
| Load Capacity | approx. 20 kg | approx. 30 kg | approx. 35 kg | |
| Resolution | 1um | 1um | 1um | 1um |
| Accuracy E1* | Ex, y ≤ (3.0+L/200) μm | |||
| Accuracy E2* | Ex, y ≤ (3.0+L/300) μm | |||
| Accuracy E3* | Ex, y ≤ (3.0+L/150) μm | |||
| Z-axis Stroke (mm) | 150(Focus) | 150(Focus) | 150(Focus) | |
| Instrument Weight (kg) | 270 | 325 | 500 | |
| Dimension (mm) | 670*660*950 | 670*660*950 | 800*1040*1020 | |
| Motor | Three-axis Max. Velocity | X,Y: 400mm/s Z: 200mm/s | ||
| Three-Axis Positioning Accuracy | 0.001mm | |||
| Camera | TEO™ Color 1 / 2 "CCD Camera | |||
| Imaging System | Zoom Lens | coaxial optical manual zoom lens | ||
| Zoom Lens Magnification | 0.7-4.5X | |||
| Video Magnification | 20-128X | |||
| FOV | 11.1-1.7mm | |||
| Power Consumption | 600W | |||
FAQ:
Q. When can I get the price of the cnc spare parts?
A. We usually quote within 24 hours after we got your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
Q. How can I get the accurate price ?
A.There are some basic specs we need to know for price calculate, that are: Exact drawings, Materials, Surface treatment. Please suggest us your order quantity too.
Q. Do you accept the OEM?
A. OEM is welcome. We can custom the good according to your design.
Q. What is the shipping ?
A:By express(FedEx, UPS, DHL, TNT, EMS, etc...),By Air,by shipping.
Q. How do I pay for the order?
A.The common payments are T/T(Telegraphic Transfer),western union ,
Q. I have an idea for a new product, but don't know if it can be manufactured. Can you help?
A. Yes! We are always happy to work with potential customers to evaluate the technical feasibility of your idea or design and we can advise on materials, tooling and likely set-up costs.
