Product Details:
|
| Warranty: | 2 Years, 24 Months | Place Of Origin: | Guangdong,China |
|---|---|---|---|
| Model Number: | GSA-W17 | Stroke(mm): | 200*100*200 |
| Metal Table Size(mm): | 345*250 | Z Measure Accuracy(μm): | 5.0+L/100 |
| Machine Size (mm): | 750*1300*1500 | Glass Size(mm): | 223*143 |
| High Light: | Video Measurement System,Visual Measuring System |
||
Microcomputer controlled 3D video measurement machine used for laboratory
product presentation:
Video measuring machine can accurately measure points, lines, circles and other elements, and has a powerful report output function, especially suitable for mass measurement of a wide range of products. Optical measurement system can accurately measure points, lines, circles and other elements, and has a powerful report output function, especially suitable for mass measurement of a wide range of products. Widely used in machinery, electronics, mold, injection molding, hardware, rubber, low-voltage electrical appliances, magnetic materials, precision hardware, precision stamping, connectors, connectors, terminals, mobile phones, household appliances, computers (computers), liquid crystal TV (LCD), printed circuit boards (PCB), automotive, medical instruments, clocks, instruments and other industries. Widely used in machinery, electronics, mold, injection molding, hardware, rubber, low-voltage electrical appliances, magnetic materials, precision hardware, precision stamping, connectors, connectors, terminals, mobile phones, household appliances, computers (computers), liquid crystal TV (LCD), printed circuit boards (PCB), automotive, medical instruments, clocks, instruments and other industries.
Measurement object:
LCD, FPC, PCB, circuit boards, screws, springs, watches, watches, meters, connectors (connectors, terminals), gears, cams, threads, radius templates, thread templates, wires and cables, tools, bearings, hardware , Stamping parts, screens, test screens, cement screens, mesh panels (steel mesh, SMT template), etc.
Measuring element:
Length, width, height, hole distance, spacing, Pin spacing, thickness, arc, diameter, radius, groove, angle, R angle, etc.
Parameter:
| Model | GSA-W17 | GSA-W17 | GSA-W17 | |
| Stroke(mm) | 300×200×200 | 400x300x200 | 500x400x200 | |
| Machine size (mm) | 850×1300×1500 | 1000x1400x1550 | 1200x1500x1550 | |
| Metal Table size(mm) | 460X360 | 460X360 | 460X360 | |
| Glass size(mm) | 340X250 | 340X250 | 340X250 | |
| Machine weight (kg) | 250 | 350 | 450 | |
| Glass table loading weight(kg) | 20 | 25 | 25 | |
| X ,Y measure accuracy (μm) | 3.0+L/150 | |||
| Z measure accuracy(μm) | 5.0+L/100 | |||
| X,Y Axle Run speed | 0-200mm/S(selection) | |||
| Z Axle Run speed | 0-100m/S(Selection) | |||
| Repeated accuracy(mm) | 0.005 | |||
| Operation Mode | software | |||
| Grating Ruler | 0.001mm Glass Rating | |||
| X,Y Axle Guide Rail | · Domestic precision cross-anti-dislocation guide | |||
| Z Axle Guide Rail | Taiwan” Shangyin” H grade precision linear guide | |||
| Z Axle lead screw | Taiwan TBI ” grinding ball screw | |||
| Bearing | Japan original "NSK" double case combination centripetal ball bearing | |||
| Motor | “TIGER”Ac synchronous servo motor, positioning accuracy ≤0.003mm | |||
| Motion Controller | ZL4000(Full closed-loop controller) | |||
| Camera | SBK-HC536 1/2inch 700 color high definition camera (with white balance function) | |||
| Video Card | SV-2000High resolution color card | |||
| Light Source | Rim Light | Profile LED cold light source, transmission light and condenser lens to realize parallel light irradiation | ||
| Surface Light | Four ring eight zone LED cold light source, software control, reduce electrical component damage. | |||
| · Optical lenses | 6.5:1 continuous variable caliper lens | |||
FQA:
1. How to choose the most suitable Mechanical Equipment ?
Our professional team will give you the best suggestion as long as you tell us what kind of test you need to do andthe required specification.
2. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15~20 working days after deposit receipt. If you are in urgent need, we can consider making special arrangement for you.
3. Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines
according to your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
4. Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange hotel and pick up you from airport.
5. Do you have customers of our country before?
Now our testing machines have been sold to more than 80 countries, like USA, Canada, Russia,UK, Italy, Germany, European , India, Pakistan, Philippine, Singapore, Malaysia,Thailand , Vietnam, Korea,Saudi Arabia,Brazil...and so on.
6. How about your warranty?
Generally,our warranty is two years. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers may go to your place for better service.
7. How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
8. What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging - balance payment - packing - delivery - customer receiving - after service.
9. How to install and use the product?
The product is shipped with an operating instructions and video of English version.
