Laser Based Vision Measurement System Manufacturers Directe Verkoop

Laser Based Machine Vision Measurement System ,Manufacturers Directe Verkoop

Description:

Machine vision measurement system is composed of camera, lens, light source, image acquisition card and computer, through the image acquisition card the image of the measured object is transferred to the computer, after image processing, will obtain the measured object size, geometric shape and surface quality information for calculation and processing, and then according to the preset target parameters for automatic measurement or manual measurement. In the production process, the functional characteristics of the machine vision measurement system can be summarized through the use of the process. This paper mainly introduces the functional characteristics of machine vision measurement system.

Characteristics:

First, non-contact measurement

Non-contact measurement technology is the non-contact measurement of the measured object through the CCD camera, or directly with the image acquisition card, special image acquisition card and other equipment connected to the measured object, using the CCD camera to input the image of the object into the computer, and the corresponding image processing and analysis, and then the obtained results and the corresponding standards are compared. To realize the size of the object, shape, surface quality and other information measurement. According to the structure and installation of CCD camera, it can be divided into traditional CCD camera measurement and industrial lens measurement. Due to the high price of industrial lenses, most of the traditional cameras are used to achieve non-contact measurement.

second, good real-time performance

In the measurement system, no matter the light source, the lens or the image acquisition card, there is a certain dynamic range, even in the actual situation, the dynamic range will be limited to a certain extent. The machine vision measurement system uses a CMOS sensor to replace the traditional photoelectric sensor. The CMOS sensor is a digital signal converter, which converts analog signals into digital signals. The dynamic range of CMOS sensor is larger than that of traditional photoelectric sensor, so when the measured object is changing, it can also respond in time, which improves the real-time performance of machine vision measurement system.

thirdly. Wide application range of the system

Machine vision measurement system has been widely used in all walks of life, such as: semiconductor manufacturing, packaging industry, etc. In the semiconductor manufacturing industry, machine vision measurement system is used in the semiconductor production process size detection; In the automobile manufacturing industry, machine vision measurement system is used for the inside and outside of the automobile body surface and body size detection; In the packaging industry, machine vision measurement system is used for the size detection of various commodity packaging. At the same time, machine vision measurement system is also widely used in the printed circuit board industry, packaging and printing industry, textile and garment industry, machinery industry, etc. The application range of machine vision measurement system is very wide, but because the machine vision measurement technology is still developing and improving, it still has a great space for development in automobile manufacturing, machinery manufacturing and other fields.

Technical Specifications And Parameters:

FQA:

1.Are your company a trading one or a factory ?


Factory + trade (integration),17 years focusing on test instruments field,11 years exporting experience.

2.How to choose the most suitable products?


Our professional team will give you the best suggestion as long as you tell us what kind of test you need to do and the required specification.

3.What’s the delivery term?


At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are

in urgent need, we can consider making special arrangement for you.

4.Do you accept customization service?


Yes, of course, we can not only offer standard machines, but also customized machines according to your request. Don’t hesitate to tell us your

requirement, we will try our best to meet your needs.

5.Can we visit your factory before order?


Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange hotel and pick up you from airport.

6.Do you have customers of our country before?


Now our testing machines have been sold to more than 70 countries, like USA, Canada, Russia,UK, Italy, Germany, European Union, India,

Pakistan, Philippines, Singapore, Thailand and Vietnam, Brazil and so on.

7.How about your warranty?


Generally, our warranty is one year. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers

may go to your place for better service.

8.How about the packing for machine, is it safely protected during transportation?


Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air

without damage.

9.What is the order process?


Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging - balance payment - packing -

delivery - customer receiving - after service.

10.How to install and use the product


The product is shipped with an operating instructions and video of English version.
